Запчасти Komatsu WA480-6 ТРАНСМИССИЯ (ECMV КЛАПАН ДЛЯ 3 И 4)(№8-9) СИЛОВАЯ ПЕРЕДАЧА

|$12

714-07-30004

TRANSMISSION ASS'Y

SN: 85366-90000

1шт.

|$13

714-07-30001

TRANSMISSION ASS'Y

SN: 85165-85365

1шт.

|$14

714-07-30000

TRANSMISSION ASS'Y

SN: 85001-85164

1шт.

|$$4

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-64A0.

-1шт.

|$16

714-07-30014

TRANSMISSION ASS'Y

SN: 85366-90000

1шт.

|$17

714-07-30011

TRANSMISSION ASS'Y

SN: 85165-85365

1шт.

|$18

714-07-30010

TRANSMISSION ASS'Y

SN: 85001-85164

1шт.

|$$8

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0, 52A1, 53A0 TO 61A0, 58A1, 59A1, 62A1 TO 64A1.

-1шт.

|$20

714-07-30024

TRANSMISSION ASS'Y

SN: 85366-90000

1шт.

|$21

714-07-30021

TRANSMISSION ASS'Y

SN: 85165-85365

1шт.

|$22

714-07-30020

TRANSMISSION ASS'Y

SN: 85001-85164

1шт.

|$$12

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A2 TO F4350-64A0.

-1шт.

|$24

714-07-30034

TRANSMISSION ASS'Y

SN: 85366-90000

1шт.

|$25

714-07-30031

TRANSMISSION ASS'Y

SN: 85165-85365

1шт.

|$26

714-07-30030

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 85001-85164

1шт.

|$$16

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A2 TO F4350-64A1.

-1шт.

1

01010-81060

BOLT

SN: 85001-90000

6шт.

2

01643-31032

WASHER

SN: 85001-90000

6шт.

3

01011-81025

BOLT

SN: 85001-90000

1шт.

4

01643-31032

WASHER

SN: 85001-90000

1шт.

5

01011-81005

BOLT

SN: 85001-90000

2шт.

6

01643-31032

WASHER

SN: 85001-90000

2шт.

7

01011-81020

BOLT

SN: 85001-90000

1шт.

8

01643-31032

WASHER

SN: 85001-90000

1шт.

9

07000-73028

O-RING (K1)(K3)

SN: 85001-90000

2шт.

10

07000-72015

O-RING (K1)(K3)

SN: 85001-90000

24шт.

11

07000-72012

O-RING (K1)(K3)

SN: 85001-90000

2шт.

12

07000-73045

O-RING (K1)(K3)

SN: 85001-90000

1шт.

13

07000-73026

O-RING (K1)(K3)

SN: 85001-90000

1шт.

14

08193-21012

CLIP

SN: 85001-90000

1шт.

15

6150-81-6940

SPACER

SN: 85001-90000

1шт.

16

01010-81075

BOLT

SN: 85001-90000

1шт.

17

01643-31032

WASHER

SN: 85001-90000

1шт.
