Запчасти Komatsu WA480-6 LC CENTRAL СМАЗКА - ЗАДН. РАМА ФИДЕР J ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

|$1

0

FEEDER ASSEMBLY, REAR FRAME

SN: H60470-UP

1шт.

\See Fig.J4710-0

See Fig.J4710-01A0

CENTRAL LUBRICATION - OVERVIEW AND PUMP CONNECTION

-1шт.

1

421-09-H5030

FEEDER

SN: H60470-UP

1шт.

2

42W-09-H4650

VALVE

SN: H60470-UP

2шт.

3

421-09-H4550

CHECK VALVE

SN: H60470-UP

3шт.

4

425-09-H0720

ELBOW

SN: H60470-UP

1шт.

5

421-09-H3870

LUBRICATION NIPPLE

SN: H60470-UP

1шт.

6

42W-09-H3350

CAP

SN: H60470-UP

1шт.

7

419-09-H2780

UNION

SN: H60470-UP

1шт.

8

423-00-H1920

BUSHING

SN: H60470-UP

4шт.

9

42W-09-H0P00

HOSE, 5M

SN: H60470-UP

-26шт.

|$11

42W-09-H0P01

HOSE, 10M

SN: H60470-UP

-26шт.

|$12

42W-09-H0P02

HOSE, 25M

SN: H60470-UP

-26шт.

10

42T-09-H3810

TUBE

SN: H60470-UP

3шт.

11

423-00-H0P12

TUBE, 90°

SN: H60470-UP

1шт.

12

01252-70640

SCREW

SN: H60470-UP

3шт.

\See Fig.J4710-0

See Fig.J4710-04A0

CENTRAL LUBRICATION - FRONT FRAME 2ND FEEDER

-1шт.

\See Fig.J4710-1

See Fig.J4710-12A0

CENTRAL LUBRICATION - REAR FRAME

-1шт.
