Запчасти Komatsu WA480-6 LC CENTRAL СМАЗКА - ПЕРЕДН. РАМА 2 ФИДЕР J ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

|$1

0

FEEDER ASSEMBLY, FRONT FRAME

SN: H60470-UP

1шт.

\See Fig.J4710-0

See Fig.J4710-01A0

CENTRAL LUBRICATION - OVERVIEW AND PUMP CONNECTION

-1шт.

1

421-09-H0P10

FEEDER

SN: H60470-UP

1шт.

2

42W-09-H4650

VALVE

SN: H60470-UP

4шт.

3

425-09-H0600

SWITCH, CYCLE

SN: H60470-UP

1шт.

4

421-09-H4520

UNION

SN: H60470-UP

1шт.

5

419-09-H2780

UNION

SN: H60470-UP

1шт.

6

425-09-H0240

ELBOW

SN: H60470-UP

2шт.

7

421-09-H3870

LUBRICATION NIPPLE

SN: H60470-UP

2шт.

8

42W-09-H3350

CAP

SN: H60470-UP

2шт.

9

425-09-H0720

ELBOW

SN: H60470-UP

1шт.

10

42W-09-H4650

VALVE

SN: H60470-UP

1шт.

11

423-09-H4050

SCREW

SN: H60470-UP

2шт.

12

01252-70640

SCREW

SN: H60470-UP

1шт.

13

421-S96-H590

WIRING HARNESS

SN: H60470-UP

1шт.

14

423-00-H1920

BUSHING

SN: H60470-UP

12шт.

15

42W-09-H0P00

HOSE, 5M

SN: H60470-UP

-26шт.

15

42W-09-H0P01

HOSE, 10M

SN: H60470-UP

-26шт.

15

42W-09-H0P02

HOSE, 25M

SN: H60470-UP

-26шт.

16

42T-09-H2300

TUBE

SN: H60470-UP

6шт.

17

425-09-H0260

TUBE

SN: H60470-UP

4шт.

18

423-00-H2060

TUBE, 90°

SN: H60470-UP

1шт.

19

421-00-H0P13

TUBE

SN: H60470-UP

1шт.

\See Fig.J4710-0

See Fig.J4710-02A0

CENTRAL LUBRICATION - BELLCRANK FEEDER

-1шт.

\See Fig.J4710-0

See Fig.J4710-03A0

CENTRAL LUBRICATION - FRONT FRAME 1ST FEEDER

-1шт.

\See Fig.J4710-0

See Fig.J4710-05A0

CENTRAL LUBRICATION - REAR FRAME FEEDER

-1шт.

\See Fig.J4710-0

See Fig.J4710-06A0

CENTRAL LUBRICATION - PUMP

-1шт.
