Запчасти Komatsu WA480-5L ТРАНСМИССИЯ (2 И 3 МУФТА) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$4

TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)

SN: A37047-UP

-1шт.

|$5

TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)

SN: A37001-A37046

-1шт.

|$6

TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)

SN: A37047-UP

-1шт.

|$7

TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)

SN: A37001-A37046

-1шт.

|$10

714-07-22033

CLUTCH ASS'Y,2ND AND 3RD

SN: A37001-UP

1шт.

1

714-07-22134

SHAFT ASS'Y,2ND AND 3RD

SN: A37001-UP

1шт.

2

714-07-22661

PISTON,RANGE

SN: A37001-UP

2шт.

3

714-12-19711

DISC

SN: A37001-UP

17шт.

4

714-16-19730

PLATE,SEPARATE

SN: A37001-UP

19шт.

5

56D-15-12710

SPRING,WAVE

SN: A37047-UP

17шт.

|$20

0

SPRING,WAVE

SN: A37001-A37046

17шт.

6

714-12-12610

PLATE,END

SN: A37001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: A37001-UP

2шт.

8

714-16-19220

RING,SEAL

SN: A37001-UP

2шт.

9

714-07-19320

RING,SEAL (KIT)

SN: A37001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: A37001-UP

4шт.

11

714-23-19430

BEARING,NEEDLE

SN: A37001-UP

3шт.

12

714-07-22462

GEAR,2ND

SN: A37001-UP

1шт.

13

714-07-22452

GEAR, 41 TEETH,3RD

SN: A37001-UP

1шт.

14

714-07-22532

GEAR, 53 TEETH,OUTPUT

SN: A37001-UP

1шт.

15

569-15-49530

RING,SNAP

SN: A37001-UP

1шт.

16

714-07-22542

GEAR, 29 TEETH,4TH

SN: A37001-UP

1шт.

17

714-07-29340

BEARING

SN: A37001-UP

1шт.

18

714-07-29350

BEARING

SN: A37001-UP

1шт.

19

419-15-12122

RING,SEAL (KIT)

SN: A37001-UP

3шт.

|$35

714-07-05020

SERVICE KIT,TRANSMISSION

SN: A37001-UP

1шт.

|$36

714-07-05080

SERVICE KIT,TRANSMISSION (WITH LOCK-UP)

SN: A37001-UP

1шт.
