Запчасти Komatsu WA480-5L ЛЕСТНИЦА (СУППОРТ КРЕПЛЕНИЕ) ЧАСТИ КОРПУСА

1

01010-D1230

BOLT

SN: A37001-UP

4шт.

2

01643-71232

WASHER

SN: A37001-UP

4шт.

3

01010-81235

BOLT

SN: A37001-UP

4шт.

4

175-54-34170

WASHER

SN: A37001-UP

4шт.

5

421-54-34312

PLATE,NOT USED WITH WASTE HANDLER

SN: A37001-UP

1шт.

6

01010-D1230

BOLT,NOT USED WITH WASTE HANDLER

SN: A37001-UP

2шт.

7

01643-71232

WASHER,NOT USED WITH WASTE HANDLER

SN: A37001-UP

2шт.

8

01010-D1025

BOLT,NOT USED WITH WASTE HANDLER

SN: A37001-UP

8шт.

9

01643-71032

WASHER,NOT USED WITH WASTE HANDLER

SN: A37001-UP

8шт.

10

FLOOR,(SEE FIG. M4310-02A0)

SN: A37001-UP

-1шт.

11

BRACKET,(SEE FIG. M4310-02A0)

SN: A37001-UP

-1шт.

12

PLATE,(SEE FIG. M4310-02A0)

SN: A37001-UP

-1шт.

13

FLOOR,(SEE FIG. M4310-01A0)

SN: A37001-UP

-1шт.

14

BRACKET,(SEE FIG. M4310-01A0)

SN: A37001-UP

-1шт.

15

PLATE,(SEE FIG. M4310-01A0)

SN: A37001-UP

-1шт.
