Запчасти Komatsu WA480-5 КАБИНА ROPS (GPS АНТЕННА И ПЛАСТИНА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

423-926-3070

ROPS CAB ASS'Y,(A+B+C+D)

SN: 80001-UP

1шт.

|1

423-926-3080

ROPS CAB ASS'Y,(A+B+C+D+E)

SN: 80001-UP

1шт.

|1

423-926-3090

ROPS CAB ASS'Y,(A+C+D+J)

SN: 80001-UP

1шт.

|1

424-926-3090

ROPS CAB ASS'Y,(B+C+D+K)

SN: 80001-UP

1шт.

|1

424-926-3100

ROPS CAB ASS'Y,(B+C+D+E+K)

SN: 80001-UP

1шт.

|1

424-926-3200

ROPS CAB ASS'Y,(C+D+J+K)

SN: 80001-UP

1шт.

|1

424-926-3900

ROPS CAB ASS'Y,(A+B+C+D+F)

SN: 80001-UP

1шт.

|1

423-926-3050

ROPS CAB ASS'Y,(A+B+C+D+E+F)

SN: 80001-UP

1шт.

|1

421-925-3080

ROPS CAB ASS'Y,(A+C+D+F+J)

SN: 80001-UP

1шт.

|1

421-925-3090

ROPS CAB ASS'Y,(C+D+F+J+K)

SN: 80001-UP

1шт.

|$$11

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25A4.

-1шт.

|$$12

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|$$13

A = AIR CONDITIONER

-1шт.

|$$14

B = AM¤FM RADIO

-1шт.

|$$15

C = E.C.S.S

-1шт.

|$$16

D = KOMTRAX

-1шт.

|$$17

E = LOAD METER

-1шт.

|$$18

F = YELLOW LAMP

-1шт.

|$$19

J = RADIO¤ CASSETTE

-1шт.

|$$20

K = AUTO AIR CONDIT.

-1шт.

1

8A13-10-1200

CABLE

SN: 80001-UP

1шт.

2

8A13-10-1310

ANTENNA,GPS

SN: 80001-UP

1шт.

3

421-925-3470

CUSHION

SN: 80001-UP

2шт.

4

421-925-3480

CUSHION

SN: 80001-UP

1шт.

5

09970-00230

PLATE¤ MARK,GALEO

SN: 80001-UP

2шт.
