Запчасти Komatsu WA480-5 КАБИНА ROPS (РАДИО) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

421-926-3041

ROPS CAB ASS'Y,(A+B+G)

SN: 80001-UP

1шт.

|1

421-926-3021

ROPS CAB ASS'Y,(A+B+C+E)

SN: 80001-UP

1шт.

|1

424-926-3400

ROPS CAB ASS'Y,(B+C+K)

SN: 80001-UP

1шт.

|1

424-926-3500

ROPS CAB ASS'Y,(B+C+E+K)

SN: 80001-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25A0.

-1шт.

|1

423-926-3070

ROPS CAB ASS'Y,(A+B+C+D)

SN: 80001-UP

1шт.

|1

423-926-3080

ROPS CAB ASS'Y,(A+B+C+D+E)

SN: 80001-UP

1шт.

|1

424-926-3090

ROPS CAB ASS'Y,(B+C+D+K)

SN: 80001-UP

1шт.

|1

424-926-3100

ROPS CAB ASS'Y,(B+C+D+E+K)

SN: 80001-UP

1шт.

|$$10

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25A4.

-1шт.

|1

423-926-3400

ROPS CAB ASS'Y,(B+C+D+H)

SN: 80001-UP

1шт.

|1

424-926-3300

ROPS CAB ASS'Y,(B+C+D+H+K)

SN: 80001-UP

1шт.

|$$13

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25B6.

-1шт.

|1

424-926-3700

ROPS CAB ASS'Y,(B+C+H+K)

SN: 80001-UP

1шт.

|$$15

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25C5.

-1шт.

|$$16

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|$$17

A = AIR CONDITIONER

-1шт.

|$$18

B = AM¤FM RADIO

-1шт.

|$$19

C = E.C.S.S

-1шт.

|$$20

D = KOMTRAX

-1шт.

|$$21

E = LOAD METER

-1шт.

|$$22

G = HEAT GLASS

-1шт.

|$$23

H = A/C SIDE BLOW

-1шт.

|$$24

K = AUTO AIR CONDIT.

-1шт.

1

23S-966-5530

RADIO,AM/FM

SN: 80001-UP

1шт.

|1

08040-00100

FUSE¤ 1A

SN: 80001-UP

1шт.

|1

08040-00200

FUSE¤ 2A

SN: 80001-UP

1шт.

2

421-925-3140

PLATE

SN: 80001-UP

2шт.

3

01023-60412

SCREW

SN: 80001-UP

4шт.

4

01601-20410

WASHER,SPRING

SN: 80001-UP

2шт.

5

421-06-36141

SWITCH

SN: 80001-UP

1шт.

6

42C-56-12310

CAP

SN: 80001-UP

7шт.
