Запчасти Komatsu WA480-5 КАБИНА ROPS (ВНУТР. ПОКРЫТИЕ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

421-926-3041

ROPS CAB ASS'Y,(A+B+G)

SN: 80001-UP

1шт.

|1

421-926-3021

ROPS CAB ASS'Y,(A+B+C+E)

SN: 80001-UP

1шт.

|1

424-926-3080

ROPS CAB ASS'Y,(A+E+J)

SN: 80001-UP

1шт.

|1

424-926-3400

ROPS CAB ASS'Y,(B+C+K)

SN: 80001-UP

1шт.

|1

424-926-3500

ROPS CAB ASS'Y,(B+C+E+K)

SN: 80001-UP

1шт.

|1

424-926-3600

ROPS CAB ASS'Y,(C+J+K)

SN: 80001-UP

1шт.

|1

421-925-3790

ROPS CAB ASS'Y,(B+C+L)

SN: 80001-UP

1шт.

|1

421-925-3810

ROPS CAB ASS'Y,(B+C+E+L)

SN: 80001-UP

1шт.

|1

421-925-3820

ROPS CAB ASS'Y,(C+J+L)

SN: 80001-UP

1шт.

|1

421-925-3830

ROPS CAB ASS'Y,(C+E+J+L)

SN: 80001-UP

1шт.

|1

421-925-3030

ROPS CAB ASS'Y,(A+F)

SN: 80001-UP

1шт.

|$$12

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25A0.

-1шт.

|1

423-926-3030

ROPS CAB ASS'Y,(A)

SN: 80001-UP

1шт.

|$$14

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A2.

-1шт.

|1

421-926-3300

ROPS CAB ASS'Y,(A+J+C)

SN: 80001-UP

1шт.

|$$16

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A0.

-1шт.

|1

423-926-3070

ROPS CAB ASS'Y,(A+B+C+D)

SN: 80001-UP

1шт.

|1

423-926-3070

ROPS CAB ASS'Y,(A+B+C+D)

SN: 80001-UP

1шт.

|1

423-926-3090

ROPS CAB ASS'Y,(A+C+D+J)

SN: 80001-UP

1шт.

|1

424-926-3090

ROPS CAB ASS'Y,(B+C+D+K)

SN: 80001-UP

1шт.

|1

424-926-3100

ROPS CAB ASS'Y,(B+C+D+E+K)

SN: 80001-UP

1шт.

|1

424-926-3200

ROPS CAB ASS'Y,(C+D+J+K)

SN: 80001-UP

1шт.

|1

424-926-3900

ROPS CAB ASS'Y,(A+B+C+D+F)

SN: 80001-UP

1шт.

|1

423-926-3050

ROPS CAB ASS'Y,(A+B+C+D+E+F)

SN: 80001-UP

1шт.

|1

421-925-3080

ROPS CAB ASS'Y,(A+C+D+F+J)

SN: 80001-UP

1шт.

|1

421-925-3090

ROPS CAB ASS'Y,(C+D+F+J+K)

SN: 80001-UP

1шт.

|$$27

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25A4.

-1шт.

|$$28

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|$$29

A = AIR CONDITIONER

-1шт.

|$$30

B = AM¤FM RADIO

-1шт.

|$$31

C = E.C.S.S

-1шт.

|$$32

D = KOMTRAX

-1шт.

|$$33

E = LOAD METER

-1шт.

|$$34

F = YELLOW LAMP

-1шт.

|$$35

G = HEAT GLASS

-1шт.

|$$36

H = A/C SIDE BLOW

-1шт.

|$$37

J = RADIO¤ CASSETTE

-1шт.

|$$38

K = AUTO AIR CONDIT.

-1шт.

|$$39

L = HEATER

-1шт.

1

423-926-3940

COVER,L.H.

SN: 80001-UP

1шт.

2

423-926-3950

COVER,R.H.

SN: 80001-UP

1шт.

3

424-926-3290

DAM

SN: 80001-UP

4шт.

4

423-926-3643

COVER,REAR¤ CENTER

SN: 80001-UP

1шт.

5

423-926-3612

COVER,L.H. REAR

SN: 80001-UP

1шт.

6

423-926-3622

COVER,R.H. REAR

SN: 80001-UP

1шт.

7

23D-950-4450

BUTTON

SN: 80001-UP

18шт.

8

421-926-3760

COVER,L.H.

SN: 80001-UP

1шт.

9

421-926-3771

COVER,R.H.

SN: 80001-UP

1шт.

10

23S-55-51970

WASHER

SN: 80001-UP

6шт.

11

01225-70620

SCREW

SN: 80001-UP

6шт.

12

423-926-3772

COVER,L.H. FRONT

SN: 80001-UP

1шт.

13

423-926-3782

COVER,R.H. FRONT

SN: 80001-UP

1шт.

14

421-09-31310

CAP ASS'Y

SN: 80001-UP

4шт.

15

01224-40620

SCREW

SN: 80001-UP

4шт.

16

423-926-3512

COVER,L.H. REAR

SN: 80001-UP

1шт.

17

423-926-3521

COVER,R.H. REAR

SN: 80001-UP

1шт.

18

421-09-31310

CAP ASS'Y

SN: 80001-UP

4шт.

19

01224-40620

SCREW

SN: 80001-UP

4шт.

20

423-926-3533

COVER,L.H. CENTER

SN: 80001-UP

1шт.

21

423-926-3543

COVER,R.H. CENTER

SN: 80001-UP

1шт.

22

421-09-31310

CAP ASS'Y

SN: 80001-UP

12шт.

23

01224-40620

SCREW

SN: 80001-UP

12шт.
