Запчасти Komatsu WA480-5 КЛАПАН КОНТРОЛЯ ПОТОКА ТРАНСМИССИИ СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$7

714-07-20004

TORQFLOW ASS'Y

SN: (111869)-UP

1шт.

|$8

714-07-20002

TORQFLOW ASS'Y

SN: (111067)-(111868)

1шт.

|$9

0

TORQFLOW ASS'Y

SN: 80001-(111066)

1шт.

|$10

0

TORQFLOW ASS'Y

SN: (80001-(110482))

1шт.

|$11

714-07-20014

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: (111869)-UP

1шт.

|$12

714-07-20012

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: (111067)-(111868)

1шт.

|$13

0

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: 80001-(111066)

1шт.

|$14

0

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: (80001-(110482))

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$18

714-07-25401

VALVE ASS'Y,FLOW CONTROL

SN: (110420)-UP

1шт.

|$19

0

VALVE ASS'Y,FLOW CONTROL

SN: 80001-(110419)

1шт.

|$20

714-07-25461

BODY

SN: (110420)-UP

1шт.

|$21

714-07-25460

BODY

SN: 80001-(110419)

1шт.

1

0

BODY

SN: (110420)-UP

1шт.

1

0

BODY

SN: 80001-(110419)

1шт.

2

07042-80108

PLUG

SN: (110420)-UP

2шт.

2

07043-70108

PLUG

SN: 80001-(110419)

2шт.

3

714-07-15410

VALVE

SN: 80001-UP

1шт.

4

714-07-15420

SPRING

SN: 80001-UP

1шт.

5

714-07-15430

CHOKE

SN: 80001-UP

1шт.

6

714-07-15840

COVER

SN: 80001-UP

2шт.

7

01010-80820

BOLT

SN: 80001-UP

4шт.

8

01643-30823

WASHER

SN: 80001-UP

4шт.

9

07000-73030

O-RING (K2)

SN: 80001-UP

2шт.
