Запчасти Komatsu WA470-DZ-3 КРЕПЛЕНИЕ СТАРТЕРА(KW) [ДВИГАТЕЛЬ SADE- ДВИГАТЕЛЬ NO.7 И UP]

1\A\

X16-0406600

STARTER UNIT(11KW)

Field_2: 61589-

1шт.

|$2

600-813-8310

STARTING MOTOR A,(11KW)

Field_2: 61589-

1шт.

|$1

-1шт.

|$4

THE SAWAFUJI DENKI PART NUMBER IS THAT SD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW

-1шт.

|$1

-1шт.

1

SD1310-10030X0

YOKE ASS'Y

Field_2: 61589-

1шт.

2

SD4141-26410X0

PACKING

Field_2: 61589-

2шт.

3

SD2240-24142X0

BRACKET,REAR

Field_2: 61589-

1шт.

4

SD1331-04300X0

BRUSH HOLDER ASS'Y

Field_2: 61589-

1шт.

5

SD5250-02800X0

SPRING,BRUSH

Field_2: 61589-

4шт.

6

SD5000-10500X0

SCREW

Field_2: 61589-

2шт.

7

SD6414-02940X0

O-RING

Field_2: 61589-

2шт.

8

SD3040-12100X0

PLATE

Field_2: 61589-

1шт.

9

SD1320-07830X0

ARMATURE ASS'Y

Field_2: 61589-

1шт.

10

SD6206-01110X0

BEARING,BALL

Field_2: 61589-

1шт.

11

SD6206-01120X0

BEARING,BALL

Field_2: 61589-

1шт.

12

SD8167-0719060

BOLT

Field_2: 61589-

2шт.

13

SD2245-00830X0

CASE,GEAR

Field_2: 61589-

1шт.

14

SD5031-05700X0

SHIM

Field_2: 61589-

1шт.

15

SD2441-03200X0

SHAFT

Field_2: 61589-

1шт.

16

SD2244-06902X0

HOLDER,CENTER

Field_2: 61589-

1шт.

17

SD6410-01000X0

SEAL,OIL

Field_2: 61589-

1шт.

18

SD6206-01710X0

BEARING,BALL

Field_2: 61589-

1шт.

19

SD1361-04800X0

PINION CLUTCH ASS'Y

Field_2: 61589-

1шт.

20

SD3661-02000X0

STOPPER,PINION

Field_2: 61589-

1шт.

21

SD5221-01200X0

HOOK

Field_2: 61589-

2шт.

22

SD5058-04200X0

RING,RETAINING

Field_2: 61589-

1шт.

23

SD5010-27430X0

BOLT

Field_2: 61589-

1шт.

24

SD4141-26311X0

PACKING

Field_2: 61589-

1шт.

25

SD1372-04200X0

LEVER ASS'Y

Field_2: 61589-

1шт.

26

SD3600-17800X0

ROD

Field_2: 61589-

1шт.

27

SD4223-05200X0

HOLDER,LEVER

Field_2: 61589-

2шт.

28

SD5201-10100X0

COIL,SPRING

Field_2: 61589-

1шт.

29

SD2407-02101X0

COLIAR

Field_2: 61589-

1шт.

30

SD2244-06821X0

BRACKET,CENTER

Field_2: 61589-

1шт.

31

SD2046-14100X9

CASE ASS'Y,PINION

Field_2: 61589-

1шт.

32

SD2620-10500X9

METAL

Field_2: 61589-

1шт.

33

SD5010-26200X0

BOLT

Field_2: 61589-

5шт.

34

SD5010-26220X0

BOLT

Field_2: 61589-

1шт.

35

SD1350-10931X9

SWITCH ASS'Y,ENGAGE

Field_2: 61589-

1шт.

36

SD5010-27300X0

BOLT

Field_2: 61589-

2шт.

37

SD1599-0010010

RELAY,SAFETY

Field_2: 61589-

1шт.

38

SD1331-04300X9

BRUSH HOLDER ASS'Y,(SERVICE PARTS)

Field_2: 61589-

1шт.

39

SD5250-02800X0

SPRING,BRUSH

Field_2: 61589-

4шт.

40

SD2660-07400X6

BRUSH,(FOR 1ST SERVICE ONLY)

Field_2: 61589-

1шт.

41

SD2660-07400X7

BRUSH,(FOR 2ND SERVICE)

Field_2: 61589-

4шт.
