Запчасти Komatsu WA470-DZ-3 ТОПЛ. НАСОС(НАСОС)(/)(ВНУТР. ЧАСТИ)(№79-№78) [ДВИГАТЕЛЬ SADE- ДВИГАТЕЛЬ NO.7 И UP]

1\A\

X16-0354001

INJECTION PUMP UNIT

Field_2: 70946-\7\

1шт.

|$2

6152-72-1441

INJECTION PUMP A

Field_2: 70946-74800

1шт.

|$1

-1шт.

|$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3K5A TO A4010-G3K5A

-1шт.

|$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW

-1шт.

|$1

-1шт.

|$7

DK 106067-1520

PUMP ASS'Y

Field_2: 70946-74800

1шт.

|$1

-1шт.

|$9

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3K5A TO A4010-C3K5A

-1шт.

|$1

-1шт.

|$11

DK 134150-3720

PLUNGER ASS'Y

Field_2: 70946-74800

6шт.

1

DK 134131-1020

FLANGE

Field_2: 70946-74800

1шт.

2

DK 134153-3620

PLUNGER ASS'Y

Field_2: 70946-74800

1шт.

3

DK 134110-8920

VALVE,DELIVERY

Field_2: 70946-74800

1шт.

4

DK 134116-4720

HOLDER,DELIVERY VALVE

Field_2: 70946-74800

1шт.

5

DK 029632-2070

O-RING

Field_2: 70946-74800

1шт.

6

DK 134117-0500

STOPPER

Field_2: 70946-74800

1шт.

7

DK 134112-2000

SPRING

Field_2: 70946-74800

1шт.

8

DK 134115-0100

GASKET

Field_2: 70946-74800

1шт.

9

DK 029302-0140

WASHER

Field_2: 70946-74800

1шт.

10

DK 134135-0200

DEFLECTOR

Field_2: 70946-74800

1шт.

11

DK 029602-0010

RING,SNAP

Field_2: 70946-74800

1шт.

12

DK 134137-0100

RING

Field_2: 70946-74800

1шт.

13

DK 029632-9030

O-RING

Field_2: 70946-74800

1шт.

14

DK 029631-5020

O-RING

Field_2: 70946-74800

1шт.

15

DK 029631-5020

O-RING

Field_2: 70946-74800

1шт.

16

DK 139400-0900

SHIM,0.500MM

Field_2: 70946-74800

-2шт.

|$28

DK 139400-1000

SHIM,0.525MM

Field_2: 70946-74800

-2шт.

|$29

DK 139400-1100

SHIM,0.550MM

Field_2: 70946-74800

-2шт.

|$30

DK 139400-1200

SHIM,0.575MM

Field_2: 70946-74800

-2шт.

|$31

DK 139400-1300

SHIM,0.600MM

Field_2: 70946-74800

-2шт.

|$32

DK 139400-1400

SHIM,0.625MM

Field_2: 70946-74800

-2шт.

|$33

DK 139400-1500

SHIM,0.650MM

Field_2: 70946-74800

-2шт.

|$34

DK 139400-1600

SHIM,0.675MM

Field_2: 70946-74800

-2шт.

|$35

DK 139400-1700

SHIM,0.700MM

Field_2: 70946-74800

-2шт.

|$36

DK 139400-1800

SHIM,0.725MM

Field_2: 70946-74800

-2шт.

|$37

DK 139400-1900

SHIM,0.750MM

Field_2: 70946-74800

-2шт.

|$38

DK 139400-2000

SHIM,0.775MM

Field_2: 70946-74800

-2шт.

|$39

DK 139400-2100

SHIM,0.800MM

Field_2: 70946-74800

-2шт.

|$40

DK 139400-2200

SHIM,0.825MM

Field_2: 70946-74800

-2шт.

|$41

DK 139400-2300

SHIM,0.850MM

Field_2: 70946-74800

-2шт.

|$42

DK 139400-2400

SHIM,0.875MM

Field_2: 70946-74800

-2шт.

|$43

DK 139400-2500

SHIM,0.900MM

Field_2: 70946-74800

-2шт.

|$44

DK 139400-2600

SHIM,0.925MM

Field_2: 70946-74800

-2шт.

|$45

DK 139400-2700

SHIM,0.950MM

Field_2: 70946-74800

-2шт.

|$46

DK 139400-2800

SHIM,0.975MM

Field_2: 70946-74800

-2шт.

|$47

DK 139400-2900

SHIM,1.000MM

Field_2: 70946-74800

-2шт.

|$48

DK 139400-3000

SHIM,1.025MM

Field_2: 70946-74800

-2шт.

|$49

DK 139400-3100

SHIM,1.050MM

Field_2: 70946-74800

-2шт.

|$50

DK 139400-3200

SHIM,1.075MM

Field_2: 70946-74800

-2шт.

|$51

DK 139400-3300

SHIM,1.100MM

Field_2: 70946-74800

-2шт.

|$52

DK 139400-3400

SHIM,1.125MM

Field_2: 70946-74800

-2шт.

|$53

DK 139400-3500

SHIM,1.150MM

Field_2: 70946-74800

-2шт.

|$54

DK 139400-3600

SHIM,1.175MM

Field_2: 70946-74800

-2шт.

|$55

DK 139400-3700

SHIM,1.200MM

Field_2: 70946-74800

-2шт.

|$56

DK 139400-3800

SHIM,1.225MM

Field_2: 70946-74800

-2шт.

|$57

DK 139400-3900

SHIM,1.250MM

Field_2: 70946-74800

-2шт.

|$58

DK 139400-4000

SHIM,1.275MM

Field_2: 70946-74800

-2шт.

|$59

DK 139400-4100

SHIM,1.300MM

Field_2: 70946-74800

-2шт.

|$60

DK 139400-4200

SHIM,1.325MM

Field_2: 70946-74800

-2шт.

|$61

DK 139400-4300

SHIM,1.350MM

Field_2: 70946-74800

-2шт.

|$62

DK 139400-4400

SHIM,1.375MM

Field_2: 70946-74800

-2шт.

|$63

DK 139400-4500

SHIM,1.400MM

Field_2: 70946-74800

-2шт.

|$64

DK 139400-4600

SHIM,1.425MM

Field_2: 70946-74800

-2шт.

|$65

DK 139400-4700

SHIM,1.450MM

Field_2: 70946-74800

-2шт.

|$66

DK 139400-4800

SHIM,1.475MM

Field_2: 70946-74800

-2шт.

|$67

DK 139400-4900

SHIM,1.500MM

Field_2: 70946-74800

-2шт.

|$68

DK 139400-5000

SHIM,1.525MM

Field_2: 70946-74800

-2шт.

|$69

DK 139400-5100

SHIM,1.550MM

Field_2: 70946-74800

-2шт.

|$70

DK 139400-5200

SHIM,1.575MM

Field_2: 70946-74800

-2шт.

|$71

DK 139400-5300

SHIM,1.600MM

Field_2: 70946-74800

-2шт.

|$72

DK 139400-5400

SHIM,1.625MM

Field_2: 70946-74800

-2шт.

|$73

DK 139400-5500

SHIM,1.650MM

Field_2: 70946-74800

-2шт.

|$74

DK 139400-5600

SHIM,1.675MM

Field_2: 70946-74800

-2шт.

|$75

DK 139400-5700

SHIM,1.700MM

Field_2: 70946-74800

-2шт.

|$76

DK 139400-5800

SHIM,1.725MM

Field_2: 70946-74800

-2шт.

|$77

DK 139400-5900

SHIM,1.750MM

Field_2: 70946-74800

-2шт.

|$78

DK 139400-6000

SHIM,1.775MM

Field_2: 70946-74800

-2шт.

|$79

DK 139400-6100

SHIM,1.800MM

Field_2: 70946-74800

-2шт.

|$80

DK 139400-6200

SHIM,1.825MM

Field_2: 70946-74800

-2шт.

|$81

DK 139400-6300

SHIM,1.850MM

Field_2: 70946-74800

-2шт.

|$82

DK 139400-6400

SHIM,1.875MM

Field_2: 70946-74800

-2шт.

|$83

DK 139400-6500

SHIM,1.900MM

Field_2: 70946-74800

-2шт.

|$84

DK 139400-6600

SHIM,1.925MM

Field_2: 70946-74800

-2шт.

|$85

DK 139400-6700

SHIM,1.950MM

Field_2: 70946-74800

-2шт.

|$86

DK 139400-6800

SHIM,1.975MM

Field_2: 70946-74800

-2шт.

17

DK 134132-0300

WASHER

Field_2: 70946-74800

12шт.

18

DK 013021-0040

NUT

Field_2: 70946-74800

12шт.

19

DK 134001-0000

BUSHING

Field_2: 70946-74800

2шт.

20

DK 134256-0000

RACK,CONTROL

Field_2: 70946-74800

1шт.

21

DK 024030-2030

PIN

Field_2: 70946-74800

1шт.

22

DK 134222-0000

BUSHING

Field_2: 70946-74800

1шт.

23

DK 134241-0320

SLEEVE,CONTROL

Field_2: 70946-74800

6шт.

24

DK 134216-0000

SEAT,SPRING

Field_2: 70946-74800

6шт.

25

DK 134215-0700

SPRING,PLUNGER

Field_2: 70946-74800

6шт.

26

DK 134217-0500

SEAT,SPRING

Field_2: 70946-74800

6шт.

27

DK 134200-0420

TAPPET ASS'Y

Field_2: 70946-74800

6шт.

|$98

DK 134204-0100

ROLLER

Field_2: 70946-74800

1шт.

|$99

DK 134205-0000

BUSHING

Field_2: 70946-74800

1шт.

|$100

DK 134203-0000

PIN

Field_2: 70946-74800

1шт.

|$101

DK 131206-0500

GUIDE

Field_2: 70946-74800

1шт.

28

DK 134034-0800

COVER

Field_2: 70946-74800

1шт.

29

DK 134042-1400

GASKET

Field_2: 70946-74800

1шт.

30

DK 12206-1640

SCREW

Field_2: 70946-74800

12шт.

31

DK 134496-0100

POINTER

Field_2: 70946-74800

1шт.

32

DK 020006-1240

BOLT

Field_2: 70946-74800

2шт.
