Запчасти Komatsu WA470-6 ТРАНСМИССИЯ (2 И 3 МУФТА) F ТРАНСМИССИЯ

|$1

421-15-H1761

TRANSMISSION ASSEMBLY

SN: H50710-H50879

1шт.

|$2

421-15-H1070

TRANSMISSION ASSEMBLY

SN: H50051-H50709

1шт.

|$3

421-15-H1771

TRANSMISSION ASSEMBLY, WITH LOCK-UP

SN: H50710-H50879

1шт.

|$4

421-15-H1060

TRANSMISSION ASSEMBLY, WITH LOCK-UP

SN: H50051-H50709

1шт.

|$5

714-07-32032

CLUTCH, 2ND AND 3RD

SN: H50051-H50879

1шт.

1

714-07-32132

SHAFT AND CYLINDER A

SN: H50051-H50879

1шт.

|$7

0

SHAFT, LOWER

SN: H50051-H50879

1шт.

|$8

0

ORIFICE

SN: H50051-H50879

1шт.

|$9

0

SCREW

SN: H50051-H50879

2шт.

|$10

0

HOUSING

SN: H50051-H50879

1шт.

|$11

0

SCREW, ORIFICE

SN: H50051-H50879

1шт.

2

714-07-22661

PISTON, RANGE

SN: H50051-H50879

2шт.

3

714-12-19711

DISK

SN: H50051-H50879

17шт.

4

714-16-19730

PLATE, SEPARATE

SN: H50051-H50879

19шт.

5

56D-15-12710

SPRING, WAVE

SN: H50051-H50879

17шт.

6

714-12-12610

PLATE, END

SN: H50051-H50879

2шт.

7

419-15-12140

RING, SNAP

SN: H50051-H50879

2шт.

8

714-16-19220

RING, SEAL

SN: H50051-H50879

2шт.

9

714-07-19320

RING, SEAL

SN: H50051-H50879

2шт.

10

714-08-19570

WASHER, THRUST

SN: H50051-H50879

4шт.

11

714-23-19430

BEARING, NEEDLE

SN: H50051-H50879

3шт.

12

714-07-32462

GEAR, 54 TEETH, 2ND

SN: H50051-H50879

1шт.

13

714-07-22452

GEAR, 41 TEETH, 3RD

SN: H50051-H50879

1шт.

14

714-07-22532

GEAR, 53 TEETH, OUTPUT

SN: H50051-H50879

1шт.

15

569-15-49530

RING, SNAP

SN: H50051-H50879

1шт.

16

714-07-22542

GEAR, 29 TEETH, 4TH

SN: H50051-H50879

1шт.

17

714-07-29340

BEARING

SN: H50051-H50879

1шт.

18

714-07-29350

BEARING

SN: H50051-H50879

1шт.

19

419-15-12122

RING, SEAL

SN: H50051-H50879

3шт.
