Запчасти Komatsu WA470-6 U-A МАРКИРОВКА ШАССИ ТАБЛИЧКИS МАРКИРОВКА

|$0

423-93-41311

PACKAGE, DECAL

SN: A46001--UP

1шт.

1

NSS

DECAL, REMOTE GREASE, CYLINDER

SN: A46001--UP

1шт.

2

NSS

DECAL, REMOTE GREASE - REAR AXLE

SN: A46001--UP

1шт.

3

NSS

DECAL, RADIATOR DRAIN

SN: A46001--UP

1шт.

4

NSS

DECAL, ENGINE OIL DRAIN

SN: A46001--UP

1шт.

5

NSS

DECAL, P/B EMERGENCY RELEASE SW

SN: A46001--UP

1шт.

6

NSS

DECAL, P/B EMERGENCY RELEASE CAUTION

SN: A46001--UP

1шт.

7

09805-03000

DECAL, SAFETY, NEVER BE ON THIS HOOD

SN: A46001--UP

2шт.

8

421-93-41310

DECAL, OIL CHART

SN: A46001--UP

1шт.

9

421-93-42240

DECAL, WA470 (L.H.)

SN: A46001--UP

1шт.

10

421-93-42250

DECAL, WA470 (R.H.)

SN: A46001--UP

1шт.

11

421-93-42230

DECAL, STRIPE

SN: A46001--UP

2шт.

12

09690-P0900

DECAL, KOMATSU

SN: A46001--UP

2шт.

13

09812-13000

DECAL, SAFETY - KEEP A SAFE DISTANCE

SN: A46001--UP

2шт.

14

09807-C0883

DECAL, SAFETY - KEEP OUT

SN: A46001--UP

2шт.

15

09960-01601

DECAL, LIFT HERE

SN: A46001--UP

4шт.

16

09669-0000E

DECAL, CAUTION - DIESEL FUEL

SN: A46001--UP

1шт.

17

09659-53000

DECAL, SAFETY - PPC ACCUMULATOR

SN: A46001--UP

1шт.

18

09659-53000

DECAL, SAFETY - BRAKE ACCUMULATOR

SN: A46001--UP

2шт.

19

09659-53000

DECAL, SAFETY - ECSS ACCUMULATOR

SN: A46001--UP

1шт.

20

NSS

PLATE, NAME (LIMITED SUPPLY)

SN: A46001--UP

1шт.

N/I

04418-13060

SCREW

SN: A46001--UP

4шт.

21

09667-03001

DECAL, SAFETY - FAN BELT

SN: A46001--UP

1шт.

22

09667-03001

DECAL, SAFETY - FAN BELT

SN: A46001--UP

2шт.

23

09161-23000

DECAL, FRAME LOCK

SN: A46001--UP

1шт.

24

09162-23000

DECAL, ARTICULATE

SN: A46001--UP

2шт.

25

09653-03001

DECAL, SAFETY - RADIATOR CAP

SN: A46001--UP

1шт.

26

09668-03001

DECAL, SAFETY - HYDRAULIC TANK CAP

SN: A46001--UP

1шт.

27

09808-03000

DECAL, SAFETY - ELECTRIC SHOCK

SN: A46001--UP

2шт.

28

09664-30011

DECAL, SAFETY - BATTERY

SN: A46001--UP

2шт.

29

20Y-00-41530

DECAL, ECOT 3

SN: A46001--UP

1шт.

30

20Y-00-41340

DECAL, PRE-FILTER CAUTION

SN: A46001--UP

1шт.

31

14X-98-35181

DECAL, REFLECTOR

SN: A46001--UP

2шт.

32

09642-13000

DECAL, INSTRUCTIONS - COOLANT

SN: A46001--UP

1шт.
