Запчасти Komatsu WA470-6 A-DY7 ТОПЛИВН. НАСОС (/) КУЗОВ ДВИГАТЕЛЬ

|$0

6251-71-1121

FUEL PUMP ASSEMBLY

1шт.

|$1

ND094100-0460

BODY ASSEMBLY

1шт.

1

ND094110-0210

HOUSING ASSEMBLY

1шт.

2

ND094040-0270

PCV ELEMENT ASSEMBLY

2шт.

3

ND094086-0090

O-RING

2шт.

4

ND094137-0010

GASKET

2шт.

5

ND094140-0040

VALVE ASSEMBLY

2шт.

6

ND094086-0100

O-RING

4шт.

7

ND949013-5880

WASHER

4шт.

8

ND92156-08081

NUT

4шт.

9

ND094162-0040

SEAT, SPRING UPPER

2шт.

10

ND094164-0010

SPRING, PLUNGER

2шт.

11

ND094165-0021

SEAT, SPRING LOWER

2шт.

12

ND094170-0100

TAPPET ASSEMBLY

2шт.

13

ND094191-0161

CAMSHAFT

1шт.

14

ND949101-0230

BEARING, ROLLER

2шт.

15

ND094104-0100

COVER, BEARING

1шт.

16

ND949150-3030

SEAL, OIL

1шт.

17

ND094086-0120

O-RING

1шт.

18

ND094095-0100

SHIM, 0.05 MM

-2шт.

|$20

ND094095-0130

SHIM, 0.10 MM

-2шт.

|$21

ND094095-0140

SHIM, 0.20 MM

-2шт.

|$22

ND094095-0150

SHIM, 0.30 MM

-2шт.

|$23

ND094095-0160

SHIM, 0.50 MM

-2шт.

19

ND094092-0010

WASHER

4шт.

20

ND949044-3320

BOLT

4шт.

21

ND094086-0110

O-RING

1шт.

22

ND094086-0130

O-RING

1шт.

23

ND094093-0050

SHIM, 0.40 MM

-2шт.

|$29

ND094093-0060

SHIM, 0.60 MM

-2шт.

|$30

ND094093-0070

SHIM, 0.80 MM

-2шт.

|$31

ND094093-0080

SHIM, 1.00 MM

-2шт.

24

ND949979-1300

SENSOR, FUEL PUMP

1шт.

|$33

ND949140-6310

O-RING

1шт.

25

ND094096-0050

SHIM, 0.15 MM

-2шт.

|$35

ND094096-0060

SHIM, 0.20 MM

-2шт.

|$36

ND094096-0070

SHIM, 0.25 MM

-2шт.

|$37

ND094096-0080

SHIM, 0.40 MM

-2шт.

26

ND90200-06081

WASHER

1шт.

27

ND90107-06161

BOLT

1шт.

28

ND090310-0500

VALVE ASSEMBLY, OVERFLOW

1шт.

29

ND090222-0070

WASHER

5шт.

30

ND949180-0310

SCREW

1шт.

31

ND090222-0120

WASHER

2шт.

32

ND949180-0060

SCREW

1шт.

33

ND949018-0350

WASHER

1шт.

34

ND090317-0480

PLUG, SCREW

1шт.

35

ND090207-0100

RING

1шт.

36

ND090244-0010

SCREW

1шт.

37

ND949010-3020

WASHER

1шт.

38

ND094086-0210

O-RING

1шт.

|$51

51

-1шт.

|$52

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

52

-1шт.
