Запчасти Komatsu WA470-6 H-A ГИДР. НАСОС. ПОГРУЗ. НАСОС (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-01A0)

SN: A46001--UP

-1шт.

|$1

PUMP SUBASSEMBLY (SEE FIG. H0210-01A0)

SN: A46001--UP

-1шт.

|$2

708-2G-04272

CYLINDER BLOCK ASSEMBLY

SN: A46001--UP

1шт.

1

NSS

BLOCK

SN: A46001--UP

1шт.

2

NSS

PLATE, VALVE

SN: A46001--UP

1шт.

3

708-18-13230

PIN

SN: A46001--UP

1шт.

4

04065-05520

RING, SNAP

SN: A46001--UP

1шт.

5

708-2G-13131

SEAT

SN: A46001--UP

1шт.

6

708-2G-13152

SPRING

SN: A46001--UP

1шт.

7

708-2G-13141

SEAT

SN: A46001--UP

1шт.

8

708-2G-13510

GUIDE, RETAINER

SN: A46001--UP

1шт.

9

708-2H-23360

PIN

SN: A46001--UP

3шт.

10

708-2G-13350

RETAINER, SHOE

SN: A46001--UP

1шт.

11

708-2G-13370

PISTON SUB ASSEMBLY

SN: A46001--UP

9шт.

|$14

708-2G-04290

CRADLE SUB ASSEMBLY

SN: A46001--UP

1шт.

12

NSS

CRADLE

SN: A46001--UP

1шт.

13

NSS

CAM, ROCKER

SN: A46001--UP

1шт.

14

04020-01434

PIN, DOWEL

SN: A46001--UP

1шт.

15

07000-F1009

O-RING

SN: A46001--UP

1шт.

16

01252-61230

BOLT

SN: A46001--UP

6шт.

|$20

20

-1шт.

|$21

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

21

-1шт.
