Запчасти Komatsu WA470-6 ТРАНСМИССИЯ (МЕХ-М ОТБОРА МОЩН-ТИ)(№8-9) СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$7

714-07-30004

TRANSMISSION ASS'Y

SN: 85350-90000

1шт.

|$8

714-07-30001

TRANSMISSION ASS'Y

SN: 85165-85349

1шт.

|$9

714-07-30000

TRANSMISSION ASS'Y

SN: 85001-85164

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-64A0.

-1шт.

|$11

714-07-30014

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 85350-90000

1шт.

|$12

714-07-30011

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 85165-85349

1шт.

|$13

714-07-30010

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 85001-85164

1шт.

|$$9

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0, 52A1, 53A0 TO 61A0, 58A1, 59A1, 62A1 TO 64A1.

-1шт.

1

714-07-26613

GEAR, 28 TEETH

SN: 85001-90000

1шт.

2

714-07-29331

BEARING

SN: 85001-90000

1шт.

3

714-07-23270

HOLDER

SN: 85001-90000

1шт.

4

01010-81230

BOLT

SN: 85001-90000

1шт.

5

01643-31232

WASHER

SN: 85001-90000

1шт.

6

714-07-26622

COLLAR

SN: 85001-90000

1шт.

7

714-07-23222

SHAFT

SN: 85001-90000

1шт.

8

714-07-23231

SHAFT

SN: 85001-90000

1шт.

9

714-07-39310

BEARING

SN: 85001-90000

2шт.

10

06040-06213

BEARING

SN: 85001-90000

2шт.

11

711-54-11660

SPACER

SN: 85001-90000

2шт.

12

04064-06525

RING,SNAP

SN: 85001-90000

2шт.

13

714-07-33410

GEAR, 87 TEETH

SN: 85001-90000

2шт.

14

04064-07025

RING,SNAP

SN: 85001-90000

2шт.

15

714-07-23710

RING

SN: 85001-90000

2шт.

16

714-07-14461

SPACER

SN: 85001-90000

4шт.

17

04065-01204

RING,SNAP

SN: 85001-90000

2шт.
