Запчасти Komatsu WA470-5 ПРИОРИТЕТН. КЛАПАН 7 РУЛЕВ. УПРАВЛЕНИЕ

1

421-64-35122

STEERING VALVE

1шт.

1A

HOUSING

EnglischBem: ORDER 421-64-35122

1шт.

2

CONTROL SLIDE

EnglischBem: ORDER 421-64-35122

1шт.

3

421-64-15710

POPPET

2шт.

4

421-64-15340

SPRING

2шт.

5

NOT USED

-1шт.

6

421-64-15780

O-RING

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (36) Kit

2шт.

7

423-64-15530

SCREW

2шт.

8

421-64-25240

COVER

1шт.

9

423-64-15540

SPRING SEAT

2шт.

10

421-64-35330

COMPRESSION SPRING

1шт.

11

421-64-25270

COVER

1шт.

12

421-64-15790

O-RING

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (36) Kit

2шт.

13

421-64-15870

O-RING

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (36) Kit

2шт.

14

421-64-25420

SCREW

4шт.

15

CONTROL SLIDE

EnglischBem: ORDER 421-64-35122

1шт.

16

421-64-15320

SHIM

-26шт.

17

423-64-15550

COMPRESSION SPRING

2шт.

18

421-64-15440

PLUG

1шт.

19

421-64-15470

O-RING

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (36) Kit

1шт.

20

421-64-15480

BACK-UP RING

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (36) Kit

1шт.

21

421-64-25290

PLUG

1шт.

22

421-64-15460

O-RING

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (36) Kit

2шт.

23

421-64-16880

VALVE

1шт.

24

421-64-15720

PLUG

2шт.

25

421-64-35340

POPPET

1шт.

26

421-64-15860

SPRING

1шт.

27

421-64-15310

PLUG

1шт.

28

421-64-15850

O-RING

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (36) Kit

1шт.

29

421-64-15810

PLUG

1шт.

30

421-64-15820

O-RING

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (36) Kit

1шт.

31

421-64-15890

VALVE

2шт.

32

421-64-15170

O-RING

2шт.

33

07000-12012

O-RING

1шт.

34

421-64-25250

SLEEVE

1шт.

35

07000-11007

O-RING

1шт.

36

421-64-05110

PACKING KIT

1шт.
