1
421-63-H1130
STEERING CYLINDER
SN: 50241-UP
1шт.
1A
421-63-H1120
STEERING CYLINDER
SN: 50241-UP
1шт.
1B
707-11-10A81
BARREL
EnglischBem: LEFT
1шт.
1C
707-11-10A91
BARREL
EnglischBem: RIGHT
1шт.
2
07040-11007
PLUG
EnglischBem: NOTE: Pos. (2) included in Pos. (1) and (1A) Kit
1шт.
2A
07002-11023
O-RING
EnglischBem: KIT
NOTE: Pos. (2A) included in Pos. (1) and (1A) Kit
1шт.
3
707-76-55520
BUSHING
EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (1A) Kit
1шт.
4
707-29-10620
HEAD COVER
EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (1A) Kit
1шт.
5
707-52-90250
PILOT
EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (1A) Kit
1шт.
6
707-51-50030
SEAL
EnglischBem: KIT
NOTE: Pos. (6) included in Pos. (1) and (1A) Kit
1шт.
7
707-51-50640
SEAL
EnglischBem: KIT
NOTE: Pos. (7) included in Pos. (1) and (1A) Kit
1шт.
8
176-63-92240
STRIPPER
EnglischBem: KIT
NOTE: Pos. (8) included in Pos. (1) and (1A) Kit
1шт.
9
07179-12062
CIRCLIP
EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (1A) Kit
1шт.
10
07000-12095
O-RING
EnglischBem: KIT
NOTE: Pos. (10) included in Pos. (1) and (1A) Kit
1шт.
11
07146-02096
BACK-UP RING
EnglischBem: KIT
NOTE: Pos. (11) included in Pos. (1) and (1A) Kit
1шт.
12
07000-12100
O-RING
EnglischBem: KIT
NOTE: Pos. (12) included in Pos. (1) and (1A) Kit
1шт.
13
721-58-50930
CYLINDER ROD
EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (1A) Kit
1шт.
14
707-76-55120
BUSHING
EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (1A) Kit
1шт.
14A
07020-00000
LUBRICATION NIPPLE
EnglischBem: NOTE: Pos. (14A) included in Pos. (1) and (1A) Kit
1шт.
15
707-36-10340
PISTON
EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (1A) Kit
1шт.
16
707-44-10180
SEAL
EnglischBem: KIT
NOTE: Pos. (16) included in Pos. (1) and (1A) Kit
1шт.
17
07156-01012
PILOT
EnglischBem: KIT
NOTE: Pos. (17) included in Pos. (1) and (1A) Kit
1шт.
18
07165-13638
NUT
EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (1A) Kit
1шт.
19
421-63-H0P06
PACKING KIT
1шт.
20
416-09-11130
STRIPPER
4шт.
