Запчасти Komatsu WA470-5 МОДУЛИРУЮЩИЙ КЛАПАН ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-07-20001

TORQFLOW ASS'Y

SN: (110483)-UP

1шт.

|1

0

TORQFLOW ASS'Y

SN: 70001-(110482)

1шт.

|1

714-07-20011

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: (110483)-UP

1шт.

|1

0

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: 70001-(110482)

1шт.

|$$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|1

714-12-25002

VALVE ASS'Y,MAIN

SN: (10139)-UP

1шт.

|1

714-12-25001

VALVE ASS'Y,MAIN

SN: 70001-(10138)

1шт.

|1

714-12-25012

VALVE ASS'Y,(WITH LOCK-UP)

SN: (10142)-UP

1шт.

|1

714-12-25011

VALVE ASS'Y,(WITH LOCK-UP)

SN: 70001-(10141)

1шт.

|1

714-07-26000

VALVE ASS'Y

SN: (10320)-UP

1шт.

|1

0

VALVE ASS'Y,MODULATION

SN: 70001-(10319)

1шт.

1

17A-15-25131

BODY

SN: 70001-UP

1шт.

2

07042-20108

PLUG

SN: 70001-UP

2шт.

3

14X-15-15850

PLUG

SN: 70001-UP

1шт.

4

07002-03034

O-RING (K2)

SN: 70001-UP

1шт.

5

714-07-25230

VALVE

SN: (10320)-UP

1шт.

|5

0

VALVE

SN: 70001-(10319)

1шт.

6

426-15-15490

VALVE

SN: 70001-UP

1шт.

7

198-15-15770

SPRING¤ (L= 30.0)

SN: 70001-UP

1шт.

8

426-15-15480

VALVE

SN: 70001-UP

1шт.

9

198-15-15570

SHIM¤ 0.50MM

SN: 70001-UP

5шт.

10

426-15-16251

SPRING¤ (L=122.0)

SN: 70001-UP

1шт.

11

426-15-16261

SPRING¤ (L=108.0)

SN: 70001-UP

1шт.

12

426-15-15810

PLUG

SN: 70001-UP

1шт.

13

07002-03034

O-RING (K2)

SN: 70001-UP

1шт.

14

12H-15-14130

SPOOL

SN: 70001-UP

1шт.

15

104-15-25490

VALVE

SN: 70001-UP

1шт.

16

125-15-15290

SPRING

SN: 70001-UP

1шт.

17

104-15-25480

VALVE

SN: 70001-UP

1шт.

18

14X-15-16210

SPRING

SN: 70001-UP

1шт.

19

12H-15-14140

GUIDE

SN: 70001-UP

1шт.

20

14X-15-15850

PLUG

SN: 70001-UP

2шт.

21

07002-03034

O-RING (K2)

SN: 70001-UP

2шт.
