Запчасти Komatsu WA470-5 ТРАНСМИССИЯ (2 И 3 МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-07-20001

TORQFLOW ASS'Y

SN: (110483)-UP

1шт.

|1

0

TORQFLOW ASS'Y

SN: 70001-(110482)

1шт.

|1

714-07-20011

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: (110483)-UP

1шт.

|1

0

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: 70001-(110482)

1шт.

|$$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|1

714-07-22033

CLUTCH ASS'Y,2ND AND 3RD

SN: (110483)-UP

1шт.

|1

0

CLUTCH,2ND AND 3RD

SN: (70001-(110482))

1шт.

1

714-07-22134

SHAFT ASS'Y,2ND AND 3RD

SN: (110483)-UP

1шт.

|1

714-07-22132

SHAFT AND CYLINDER A,2ND AND 3RD

SN: 70001-(110482)

1шт.

2

714-07-22661

PISTON,RANGE

SN: 70001-UP

2шт.

3

714-12-19711

DISC

SN: 70001-UP

17шт.

4

714-16-19730

PLATE,SEPARATE

SN: 70001-UP

19шт.

5

56D-15-12710

SPRING,WAVE

SN: (110483)-UP

17шт.

|5

0

SPRING,WAVE

SN: 70001-(110482)

17шт.

6

714-12-12610

PLATE,END

SN: 70001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 70001-UP

2шт.

8

714-16-19220

RING

SN: 70001-UP

2шт.

9

714-07-19320

RING,SEAL (K1)

SN: 70001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 70001-UP

4шт.

11

714-23-19430

BEARING,NEEDLE

SN: 70001-UP

3шт.

12

714-07-22462

GEAR,2ND

SN: 70001-UP

1шт.

13

714-07-22452

GEAR,3RD

SN: 70001-UP

1шт.

14

714-07-22532

GEAR,OUTPUT

SN: 70001-UP

1шт.

15

569-15-49530

RING

SN: 70001-UP

1шт.

16

714-07-22542

GEAR,4TH

SN: 70001-UP

1шт.

17

714-07-29340

BEARING

SN: 70001-UP

1шт.

18

714-07-29350

BEARING

SN: 70001-UP

1шт.

19

419-15-12122

RING (K1)

SN: 70001-UP

3шт.
