Запчасти Komatsu WA470-5 ТРАНСМИССИЯ (1 И 4 МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-07-20001

TORQFLOW ASS'Y

SN: (110483)-UP

1шт.

|1

0

TORQFLOW ASS'Y

SN: 70001-(110482)

1шт.

|1

714-07-20011

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: (110483)-UP

1шт.

|1

0

TORQFLOW ASS'Y,(WITH LOCK-UP)

SN: 70001-(110482)

1шт.

|$$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|1

714-07-22021

CLUTCH,1ST AND 4TH

SN: 70001-UP

1шт.

1

714-07-22122

SHAFT AND CYLINDER A,1ST AND 4TH

SN: 70001-UP

1шт.

2

714-07-22661

PISTON,RANGE

SN: 70001-UP

2шт.

3

714-12-19711

DISC

SN: 70001-UP

15шт.

4

714-16-19730

PLATE,SEPARATE

SN: 70001-UP

17шт.

5

56D-15-12710

SPRING,WAVE

SN: (110483)-UP

15шт.

|5

0

SPRING,WAVE

SN: 70001-(110482)

15шт.

6

714-12-12610

PLATE,END

SN: 70001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 70001-UP

2шт.

8

714-16-19220

RING

SN: 70001-UP

2шт.

9

714-07-19320

RING,SEAL (K1)

SN: 70001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 70001-UP

3шт.

11

714-08-19560

WASHER

SN: 70001-UP

1шт.

12

714-23-19410

BEARING,NEEDLE

SN: 70001-UP

2шт.

13

714-23-19430

BEARING,NEEDLE

SN: 70001-UP

1шт.

14

714-11-12720

SPACER

SN: 70001-UP

1шт.

15

714-07-22550

SNAP RING

SN: 70001-UP

1шт.

16

714-07-22442

GEAR,4TH

SN: 70001-UP

1шт.

17

714-07-22432

GEAR,1ST

SN: 70001-UP

1шт.

18

714-07-22512

GEAR

SN: 70001-UP

1шт.

19

714-07-29320

BEARING

SN: 70001-UP

1шт.

20

714-12-19340

BEARING,ROLLER

SN: 70001-UP

1шт.

21

419-15-12122

RING (K1)

SN: 70001-UP

3шт.
