Запчасти Komatsu WA470-5 КАБИНА ROPS (ОСВЕЩЕНИЕ) (ДЛЯ АВТОМАТИЧ. A/C) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

424-926-3400

ROPS CAB ASS'Y,(B+C+K)

SN: 70001-UP

1шт.

|1

424-926-3500

ROPS CAB ASS'Y,(B+C+E+K)

SN: 70001-UP

1шт.

|1

424-926-3600

ROPS CAB ASS'Y,(C+J+K)

SN: 70001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25A0.

-1шт.

|1

424-926-3090

ROPS CAB ASS'Y,(B+C+D+K)

SN: 70001-UP

1шт.

|1

424-926-3100

ROPS CAB ASS'Y,(B+C+D+E+K)

SN: 70001-UP

1шт.

|1

424-926-3200

ROPS CAB ASS'Y,(C+D+J+K)

SN: 70001-UP

1шт.

|$$8

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25A4.

-1шт.

|1

424-926-3300

ROPS CAB ASS'Y,(B+C+D+H+K)

SN: 70001-UP

1шт.

|$$10

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25B6.

-1шт.

|1

424-926-3700

ROPS CAB ASS'Y,(B+C+H+K)

SN: 70001-UP

1шт.

|$$12

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25C5.

-1шт.

|$$13

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|$$14

B = AM¤FM RADIO

-1шт.

|$$15

C = E.C.S.S

-1шт.

|$$16

D = KOMTRAX

-1шт.

|$$17

E = LOAD METER

-1шт.

|$$18

H = A/C SIDE BLOW

-1шт.

|$$19

J = RADIO¤ CASSETTE

-1шт.

|$$20

K = AUTO AIR CONDIT.

-1шт.

1

421-06-26210

LAMP ASS'Y,ROOM

SN: 70001-UP

1шт.

2

421-06-26250

LENS

SN: 70001-UP

2шт.

3

421-06-26260

BULB¤ 10W

SN: 70001-UP

2шт.

4

419-923-2130

SCREW

SN: 70001-UP

2шт.

5

424-926-3490

SWITCH,DOOR

SN: 70001-UP

2шт.

6

419-923-2130

SCREW

SN: 70001-UP

2шт.

7

08056-00111

CONNECTOR

SN: 70001-UP

2шт.

8

08056-00130

HOLDER

SN: 70001-UP

2шт.

9

421-926-3894

WIRING HARNESS

SN: 70001-UP

1шт.

10

424-926-3311

WIRING HARNESS

SN: 70001-UP

1шт.

11

04434-51308

CLIP

SN: 70001-UP

1шт.

12

04434-51508

CLIP

SN: 70001-UP

4шт.

13

04435-51308

CLIP

SN: 70001-UP

1шт.

14

01010-80812

BOLT

SN: 70001-UP

6шт.

15

01643-30823

WASHER

SN: 70001-UP

6шт.
