Запчасти Komatsu WA470-5 КАБИНА ROPS (ОСВЕЩЕНИЕ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

421-926-3041

ROPS CAB ASS'Y,(A+B+G)

SN: 70001-UP

1шт.

|1

421-926-3021

ROPS CAB ASS'Y,(A+B+C+E)

SN: 70001-UP

1шт.

|1

424-926-3080

ROPS CAB ASS'Y,(A+E+J)

SN: 70001-UP

1шт.

|1

421-925-3790

ROPS CAB ASS'Y,(B+C+L)

SN: 70001-UP

1шт.

|1

421-925-3810

ROPS CAB ASS'Y,(B+C+E+L)

SN: 70001-UP

1шт.

|1

421-925-3820

ROPS CAB ASS'Y,(C+J+L)

SN: 70001-UP

1шт.

|1

421-925-3830

ROPS CAB ASS'Y,(C+E+J+L)

SN: 70001-UP

1шт.

|1

421-925-3030

ROPS CAB ASS'Y,(A+F)

SN: 70001-UP

1шт.

|$$9

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25A0.

-1шт.

|1

423-926-3030

ROPS CAB ASS'Y,(A)

SN: 70001-UP

1шт.

|$$11

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A2.

-1шт.

|1

421-926-3300

ROPS CAB ASS'Y,(A+J+C)

SN: 70001-UP

1шт.

|$$13

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A0.

-1шт.

|1

423-926-3070

ROPS CAB ASS'Y,(A+B+C+D)

SN: 70001-UP

1шт.

|1

423-926-3080

ROPS CAB ASS'Y,(A+B+C+D+E)

SN: 70001-UP

1шт.

|1

423-926-3090

ROPS CAB ASS'Y,(A+C+D+J)

SN: 70001-UP

1шт.

|1

424-926-3900

ROPS CAB ASS'Y,(A+B+C+D+F)

SN: 70001-UP

1шт.

|1

423-926-3050

ROPS CAB ASS'Y,(A+B+C+D+E+F)

SN: 70001-UP

1шт.

|1

421-925-3080

ROPS CAB ASS'Y,(A+C+D+F+J)

SN: 70001-UP

1шт.

|$$20

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25A4.

-1шт.

|1

423-926-3400

ROPS CAB ASS'Y,(B+C+D+H)

SN: 70001-UP

1шт.

|$$22

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-25B6.

-1шт.

|$$23

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|$$24

A = AIR CONDITIONER

-1шт.

|$$25

B = AM¤FM RADIO

-1шт.

|$$26

C = E.C.S.S

-1шт.

|$$27

D = KOMTRAX

-1шт.

|$$28

E = LOAD METER

-1шт.

|$$29

F = YELLOW LAMP

-1шт.

|$$30

G = HEAT GLASS

-1шт.

|$$31

H = A/C SIDE BLOW

-1шт.

|$$32

J = RADIO¤ CASSETTE

-1шт.

|$$33

K = AUTO AIR CONDIT.

-1шт.

|$$34

L = HEATER

-1шт.

1

421-06-26210

LAMP ASS'Y,ROOM

SN: 70001-UP

1шт.

2

421-06-26250

LENS

SN: 70001-UP

2шт.

3

421-06-26260

BULB¤ 10W

SN: 70001-UP

2шт.

4

419-923-2130

SCREW

SN: 70001-UP

2шт.

5

424-926-3490

SWITCH,DOOR

SN: 70001-UP

2шт.

6

419-923-2130

SCREW

SN: 70001-UP

2шт.

7

08056-00111

CONNECTOR

SN: 70001-UP

2шт.

8

08056-00130

HOLDER

SN: 70001-UP

2шт.

9

421-926-3894

WIRING HARNESS

SN: 70001-UP

1шт.

10

423-926-3592

WIRING HARNESS

SN: 70001-UP

1шт.

11

04434-51308

CLIP

SN: 70001-UP

1шт.

12

04434-51508

CLIP

SN: 70001-UP

4шт.

13

04435-51308

CLIP

SN: 70001-UP

1шт.

14

01010-80812

BOLT

SN: 70001-UP

6шт.

15

01643-30823

WASHER

SN: 70001-UP

6шт.
