Запчасти Komatsu WA470-3 БЕЗОПАСН. КАБИНА, ДВЕРЬS ПРИВОДRS КАБИНА

1

421-56-H1980

DOOR ASSEMBLY

EnglischBem: LEFT

1шт.

1A

421-56-H1960

DOOR

DeutschDesc: TUER

1шт.

2

421-56-H1990

DOOR ASSEMBLY

EnglischBem: RIGHT

1шт.

2A

421-56-H1970

DOOR

DeutschDesc: TUER

1шт.

3

423-56-H0P13

GLASS

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (2) Kit

1шт.

4

421-56-H2440

GASKET

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (2) Kit

1шт.

5

421-56-H1300

RAIL

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

1шт.

6

423-56-H0P14

SCREW

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

5шт.

7

423-56-H0P15

GLASS

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

1шт.

8

421-56-H2210

PROFILE

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

1шт.

9

421-56-H2220

PROFILE

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

1шт.

10

423-56-H0P16

PROFILE

EnglischBem: 40 CM NOTE: Pos. (10) included in Pos. (1) and (2) Kit

1шт.

11

423-56-H0P16

PROFILE

EnglischBem: 27 CM NOTE: Pos. (11) included in Pos. (1) and (2) Kit

1шт.

12

421-56-H2230

PROFILE

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

1шт.

13

423-56-H0P17

GASKET DISC

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

2шт.

14

423-56-H0P18

GASKET DISC

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (2) Kit

2шт.

15

423-56-H0P19

SCREW

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

2шт.

16

423-56-H0P20

DISC

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

2шт.

17

421-00-H0760

PLAIN WASHER

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

2шт.

18

423-56-H0P21

SPRING

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

2шт.

19

423-56-H0P22

PROFILE

EnglischBem: 72 CM NOTE: Pos. (19) included in Pos. (1) and (2) Kit

2шт.

20

423-56-H0P28

PLATE

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (2) Kit

2шт.

21

423-56-H0P29

GASKET

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (2) Kit

4шт.

22

423-56-H0P25

BRACKET

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (2) Kit

2шт.

23

423-56-H0P26

SPRING

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (2) Kit

2шт.

24

423-56-H0P27

SLIDER

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

2шт.

25

423-56-H0P23

PLATE

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (2) Kit

2шт.

26

423-56-H0P24

SHEET

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (2) Kit

2шт.

27

423-56-H0P30

DISC

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (2) Kit

4шт.

28

423-56-H0P31

SCREW

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (2) Kit

4шт.

29

421-56-H1290

PLATE

EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (2) Kit

1шт.

30

423-56-H0P32

GRIP

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (2) Kit

1шт.

31

423-56-H0P33

UNDERLAY

EnglischBem: NOTE: Pos. (31) included in Pos. (1) and (2) Kit

1шт.

32

423-56-H0P34

UNDERLAY

EnglischBem: NOTE: Pos. (32) included in Pos. (1) and (2) Kit

1шт.

33

417-56-21540

HINGE

EnglischBem: NOTE: Pos. (33) included in Pos. (1) and (2) Kit

2шт.

34

423-56-H0P35

SCREW

EnglischBem: NOTE: Pos. (34) included in Pos. (1) and (2) Kit

4шт.

35

423-56-H0P36

LOCK, LHS

DeutschDesc: SCHLOSS, LHS

1шт.

36

423-56-H0P37

LOCK, RHS

DeutschDesc: SCHLOSS, RHS

1шт.

37

423-56-H0P38

SCREW

EnglischBem: NOTE: Pos. (37) included in Pos. (1) and (2) Kit

2шт.

38

421-56-H2330

CLADDING

DeutschDesc: VERKLEIDUNG

1шт.

39

421-56-H2340

CLADDING

DeutschDesc: VERKLEIDUNG

1шт.

40

421-56-H1560

HOUSING

EnglischBem: NOTE: Pos. (40) included in Pos. (1) and (2) Kit

2шт.

41

423-56-H0P21

SPRING

EnglischBem: NOTE: Pos. (41) included in Pos. (1) and (2) Kit

4шт.

42

421-56-H1650

PROTECTOR

EnglischBem: NOTE: Pos. (42) included in Pos. (1) and (2) Kit

2шт.

43

423-56-H0P39

SCREW

EnglischBem: NOTE: Pos. (43) included in Pos. (1) and (2) Kit

2шт.

44

423-56-H0P41

SCREW

EnglischBem: NOTE: Pos. (44) included in Pos. (1) and (2) Kit

7шт.

45

423-56-H0P40

GAS DAMPER

DeutschDesc: GASDAEMPFER

1шт.

46

421-06-H0P01

KEY

DeutschDesc: SCHLUESSEL

1шт.

47

42Y-00-H0480

NUT

EnglischBem: NOTE: Pos. (47) included in Pos. (1) and (2) Kit

2шт.

48

01640-20816

PLAIN WASHER

DeutschDesc: UNTERLEGSCHEIBE

2шт.

49

42X-00-H0440

NUT

DeutschDesc: MUTTER

2шт.
