Запчасти Komatsu WA470-3 КЛАПАН КОНТРОЛЯ ПОТОКА ТРАНСМИССИИ СИЛОВАЯ ПЕРЕДАЧА

|$8

714-07-10011

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|$9

714-07-10010

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$10

714-07-10051

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|$11

714-07-10050

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$12

714-07-10001

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|$13

714-07-10000

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$14

714-07-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 54001-UP

1шт.

|$15

714-07-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-54000

1шт.

|$$9

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.

-1шт.

|$17

714-07-15400

VALVE ASS'Y,FLOW CONTROL

SN: 53001-UP

1шт.

|$19

714-07-15460

BODY ASS'Y

SN: 53001-UP

1шт.

1

0

BODY

SN: 53001-UP

1шт.

2

07043-70108

PLUG

SN: 53001-UP

2шт.

3

714-07-15410

VALVE

SN: 53001-UP

1шт.

4

714-07-15420

SPRING

SN: 53001-UP

1шт.

5

714-07-15430

CHOKE

SN: 53001-UP

1шт.

6

714-07-15840

COVER

SN: 53001-UP

2шт.

7

01010-80820

BOLT

SN: 53001-UP

4шт.

8

01643-30823

WASHER

SN: 53001-UP

4шт.

9

07000-03030

O-RING (K2)

SN: 53001-UP

2шт.
