Запчасти Komatsu WA470-3 ТРАНСМИССИЯ (МЕХ-М ОТБОРА МОЩН-ТИ) СИЛОВАЯ ПЕРЕДАЧА

|$8

714-07-10011

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|$9

714-07-10010

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$10

714-07-10051

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|$11

714-07-10050

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$12

714-07-10001

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|$13

714-07-10000

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$14

714-07-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 54001-UP

1шт.

|$15

714-07-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-54000

1шт.

|$$9

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.

-1шт.

1

714-07-12142

SHAFT,PTO

SN: 53001-UP

1шт.

2

714-07-12152

COLLAR,INPUT

SN: 53001-UP

1шт.

3

06040-06208

BEARING

SN: 53001-UP

1шт.

4

04065-08025

RING,SNAP

SN: 53001-UP

1шт.

5

04064-04018

RING,SNAP

SN: 53001-UP

1шт.

6

04065-01910

RING,SNAP

SN: 53001-UP

1шт.

7

714-07-14310

GEAR, 76 TEETH,IDLER

SN: 53001-UP

1шт.

8

714-07-12330

BEARING

SN: 53001-UP

1шт.

9

714-07-14320

SPACER

SN: 53001-UP

1шт.

10

04065-01254

RING,SNAP

SN: 53001-UP

1шт.

11

714-07-14330

HUB,SPLINE

SN: 53001-UP

1шт.

12

01530-06214

NUT

SN: 53001-UP

1шт.

13

714-07-14340

SHAFT,IDLER

SN: 53001-UP

1шт.

14

07000-02055

O-RING (K1)

SN: 53001-UP

1шт.

15

01010-81235

BOLT

SN: 53001-UP

2шт.

16

01643-31232

WASHER

SN: 53001-UP

2шт.

17

714-07-14410

SHAFT

SN: 53001-UP

2шт.

18

714-07-12340

BEARING

SN: 53001-UP

2шт.

19

06040-06213

BEARING

SN: 53001-UP

2шт.

20

714-07-13210

RING,SNAP

SN: 53001-UP

2шт.

21

04064-06525

RING,SNAP

SN: 53001-UP

2шт.

22

714-07-14420

GEAR, 74 TEETH

SN: 53001-UP

1шт.

23

714-07-14430

GEAR, 65 TEETH

SN: 53001-UP

1шт.

24

714-07-14450

RING

SN: 53001-UP

2шт.

25

714-07-14461

SPACER

SN: 53001-UP

4шт.

26

04065-01204

RING,SNAP

SN: 53001-UP

2шт.

27

04065-09030

RING,SNAP

SN: 53001-UP

2шт.
