Запчасти Komatsu WA470-3 ТРАНСМИССИЯ (3-Я И 4-Я МУФТА) СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$9

714-07-10011

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|$10

714-07-10010

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$11

714-07-10051

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|$12

714-07-10050

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$13

714-07-10001

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|$14

714-07-10000

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|$15

714-07-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 54001-UP

1шт.

|$16

714-07-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-54000

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.

-1шт.

|$19

714-07-13500

CLUTCH ASS'Y,3RD AND 4TH

SN: 53001-UP

1шт.

1

714-07-13511

SHAFT ASS'Y

SN: 53001-UP

1шт.

2

714-07-12661

PISTON

SN: 53001-UP

2шт.

3

714-07-12670

DISC

SN: 53001-UP

12шт.

4

714-07-12680

PLATE,SEPARATE

SN: 53001-UP

14шт.

5

714-07-12781

SPRING,WAVE

SN: 53001-UP

12шт.

5

0

SPRING,WAVE

SN: (53001-(201980))

12шт.

6

714-07-12711

PLATE,END

SN: 53001-UP

2шт.

7

714-07-12720

RING,SEAL

SN: 53001-UP

2шт.

8

714-07-19320

RING,SEAL

SN: 53001-UP

2шт.

9

714-07-12740

RING,SEAL

SN: 53001-UP

2шт.

10

714-07-12220

WASHER,THRUST

SN: 53001-UP

2шт.

11

714-07-12210

WASHER,THRUST

SN: 53001-UP

2шт.

12

714-07-12930

WASHER,THRUST

SN: 53001-UP

1шт.

13

714-07-12250

SPACER

SN: 53001-UP

2шт.

14

56B-15-19410

BEARING,NEEDLE

SN: 54158-UP

2шт.

14

714-07-12271

BEARING,NEEDLE

SN: (106986)-(107853)

2шт.

14

0

BEARING,NEEDLE

SN: 53001-(106985)

2шт.

15

56B-15-19420

BEARING,NEEDLE

SN: 54158-UP

2шт.

15

714-07-12281

BEARING,NEEDLE

SN: (106986)-(107853)

2шт.

15

0

BEARING,NEEDLE

SN: 53001-(106985)

2шт.

16

714-07-13620

GEAR, 53 TEETH,4TH

SN: 53001-UP

1шт.

17

714-07-13541

GEAR, 43-49 TEETH,3RD

SN: 53001-UP

1шт.

18

06040-06215

BEARING

SN: 53001-UP

1шт.

19

714-07-19340

BEARING

SN: 53001-UP

1шт.

20

714-07-12290

RING,SEAL

SN: 53001-UP

3шт.
