Запчасти Komatsu WA470-3 МАРКИРОВКА(№-999) МАРКИРОВКА

|$1

421-93-21310

PLATE KIT

SN: 53001-53999

1шт.

1

0

PLATE, SAFETY,RADIATOR CAP

SN: 53001-53999

1шт.

2

0

PLATE, SAFETY,BATTERY CABLE

SN: 53001-53999

2шт.

3

0

PLATE, INSTRUCTION,RADIATOR DRAIN

SN: 53001-53999

1шт.

4

0

PLATE, SAFETY,SAFETY BAR

SN: 53001-53999

1шт.

5

0

PLATE, SAFETY,KEEP OUT

SN: 53001-53999

2шт.

6

0

PLATE, INSTRUCTION,FUEL

SN: 53001-53999

1шт.

7

0

PLATE, INSTRUCTION,ENGINE OIL DRAIN

SN: 53001-53999

1шт.

8

0

PLATE, SAFETY,HYDRAULIC TANK CAP

SN: 53001-53999

1шт.

9

0

PLATE, INSTRUCTION,CYLINDER BOTTOM PIN

SN: 53001-53999

1шт.

10

0

PLATE, INSTRUCTION,REAR AXLE PIVOT PIN

SN: 53001-53999

1шт.

11

421-93-21350

CHART, OIL

SN: 53001-53999

1шт.

12

421-93-12760

PLATE, MARK,WA470

SN: 53001-@

2шт.

13

421-93-21150

PLATE, STRIPE,L.H.

SN: 53001-@

1шт.

14

421-93-21160

PLATE, STRIPE,R.H.

SN: 53001-@

1шт.

15

421-93-21171

PLATE, MARK,KOMATSU

SN: 53001-@

1шт.

16

09960-01001

PLATE, MARK,KEEP A SAFE DISTANCE

SN: 53001-@

4шт.

17

09806-C0880

PLATE, SAFETY,FAN

SN: 53001-53999

2шт.

18

09667-A0880

PLATE, SAFETY,KEEP OUT

SN: 53001-53999

2шт.

19

09807-C0880

PLATE, SAFETY,HANDLING

SN: 53001-53999

2шт.

20

417-93-21220

PLATE, MARK,AVANCE LOADER

SN: 53001-@

2шт.
