Запчасти Komatsu WA470-3 КАБИНА ROPS (ДВЕРЬ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$6

423-926-2502

ROPS CAB ASS'Y

SN: 55731-UP

1шт.

|$7

423-926-2501

ROPS CAB ASS'Y

SN: 54259-55730

1шт.

|$8

423-926-2500

ROPS CAB ASS'Y

SN: 54001-54258

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-31A1A TO K0210-46A1.

-1шт.

|$10

423-926-2010

ROPS CAB ASS'Y

SN: 53001-53999

1шт.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-31A1 TO K0210-46A1, K0210-48A1 AND K0210-49A1.

-1шт.

|$12

423-926-2602

ROPS CAB ASS'Y,(WITH AM/FM RADIO)

SN: 55731-UP

1шт.

|$13

423-926-2601

ROPS CAB ASS'Y,(WITH AM/FM RADIO)

SN: 54259-55730

1шт.

|$14

423-926-2600

ROPS CAB ASS'Y,(WITH AM/FM RADIO)

SN: 54001-54258

1шт.

|$$10

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-31A1A TO K0210-47A2A

-1шт.

|$16

423-926-2020

ROPS CAB ASS'Y,(WITH AM/FM RADIO)

SN: 53001-53999

1шт.

|$$12

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-31A1 TO K0210-48A1.

-1шт.

1

01220-40810

SCREW

SN: 53001-UP

4шт.

2

09415-01008

CAP,(WITHOUT BEACON LAMP)

SN: 53001-UP

3шт.

3

421-56-21720

CAP

SN: 53001-UP

4шт.

4

421-54-22990

PLUG

SN: 53001-UP

2шт.

5

01220-40608

SCREW

SN: 53001-53999

4шт.

6

423-56-21960

STRIKER

SN: 53001-UP

2шт.

7

01240-00820

SCREW

SN: 53001-UP

4шт.

8

421-54-15760

WASHER

SN: 53001-UP

4шт.

9

419-54-15690

PLATE

SN: 53001-UP

4шт.

10

01010-80825

BOLT

SN: 53001-UP

12шт.

11

01643-30823

WASHER

SN: 53001-UP

12шт.

12

423-56-21710

CUSHION

SN: 53001-53999

2шт.

13

421-56-11350

SEAL,DOOR

SN: 53001-UP

2шт.
