Запчасти Komatsu WA470-3 КАБИНА ROPS (ЧАСТИ ИНТЕРЬЕРА) (/) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$6

423-926-2502

ROPS CAB ASS'Y

SN: 55731-UP

1шт.

|$7

423-926-2501

ROPS CAB ASS'Y

SN: 54259-55730

1шт.

|$8

423-926-2500

ROPS CAB ASS'Y

SN: 54001-54258

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-31A1A TO K0210-46A1.

-1шт.

|$10

423-926-2010

ROPS CAB ASS'Y

SN: 53001-53999

1шт.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-31A1 TO K0210-46A1, K0210-48A1 AND K0210-49A1.

-1шт.

|$12

423-926-2602

ROPS CAB ASS'Y,(WITH AM/FM RADIO)

SN: 55731-UP

1шт.

|$13

423-926-2601

ROPS CAB ASS'Y,(WITH AM/FM RADIO)

SN: 54259-55730

1шт.

|$14

423-926-2600

ROPS CAB ASS'Y,(WITH AM/FM RADIO)

SN: 54001-54258

1шт.

|$$10

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-31A1A TO K0210-47A2A

-1шт.

|$16

423-926-2020

ROPS CAB ASS'Y,(WITH AM/FM RADIO)

SN: 53001-53999

1шт.

|$$12

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-31A1 TO K0210-48A1.

-1шт.

1

421-926-2610

COVER,R.H.

SN: 53001-UP

1шт.

2

421-926-2620

COVER,L.H.

SN: 53001-UP

1шт.

3

421-56-21690

COVER

SN: 53001-UP

6шт.

4

421-926-2590

SHEET

SN: 53001-UP

1шт.

5

421-09-21410

SCREW

SN: 53001-UP

6шт.

6

421-09-21440

SCREW

SN: 53001-UP

2шт.

7

423-56-21950

INSULATOR

SN: 53001-UP

1шт.
