Запчасти Komatsu WA470-3 МАРКИРОВКА (С КАБИНОЙ) (АНГЛ.)(№-) МАРКИРОВКА¤ ИНСТРУМЕНТ И РЕМКОМПЛЕКТЫ

|$0

421-93-21310

PLATE KIT

SN: 50001-UP

1шт.

1

0

PLATE, SAFETY,RADIATOR CAP

SN: 50001-UP

1шт.

2

0

PLATE, SAFETY,BATTERY CABLE

SN: 50001-UP

2шт.

3

0

PLATE, INSTRUCTION,RADIATOR DRAIN

SN: 50001-UP

1шт.

4

0

PLATE, SAFETY,SAFETY BAR

SN: 50001-UP

1шт.

5

0

PLATE, SAFETY,KEEP OUT

SN: 50001-UP

2шт.

6

0

PLATE, INSTRUCTION,FUEL

SN: 50001-UP

1шт.

7

0

PLATE, INSTRUCTION,ENGINE OIL DRAIN

SN: 50001-UP

1шт.

8

0

PLATE, SAFETY,HYDRAULIC TANK CAP

SN: 50001-UP

1шт.

9

0

PLATE, INSTRUCTION,CYLINDER BOTTOM PIN

SN: 50001-UP

1шт.

10

0

PLATE, INSTRUCTION,REAR AXLE PIVOT PIN

SN: 50001-UP

1шт.

|$11

419-93-21310

PLATE KIT

SN: 50001-UP

1шт.

11

0

PLATE, OPERATING,WORK EQUIPMENT LEVER

SN: 50001-UP

1шт.

12

0

PLATE, OPERATING,WORK EQUIPMENT LEVER LOCK

SN: 50001-UP

1шт.

13

0

PLATE, NAME,RELAY

SN: 50001-UP

1шт.

14

0

PLATE, NAME,FUSE

SN: 50001-UP

1шт.

15

0

PLATE, SAFETY,BEFORE OPERATING

SN: 50001-UP

1шт.

16

0

PLATE, SAFETY,INSPECTION

SN: 50001-UP

1шт.

17

0

PLATE, SAFETY,WORK EQUIPMENT LEVER LOCK

SN: 50001-UP

1шт.

18

0

PLATE, OPERATING,STARTING SWITCH

SN: 50001-UP

1шт.

19

0

PLATE, CAUTION,EMERGENCY PARKING BRAKE CANCEL

SN: 50001-UP

1шт.

20

0

PLATE, OPERATING,EMERGENCY PARKING BRAKE SWITCH

SN: 50001-UP

1шт.

21

09602-10010

PLATE, NAME,(LIMITED SUPPLY)

SN: 50001-UP

1шт.

21

04418-13060

SCREW

SN: 50001-UP

4шт.

22

421-93-21340

CHART, OIL

SN: 50001-UP

1шт.

23

09690-B0280

PLATE, MARK,KOMATSU

SN: 50001-UP

2шт.

24

417-93-21220

PLATE, MARK,AVANCE LOADER

SN: 50001-UP

2шт.

25

421-93-12760

PLATE, MARK,WA470

SN: 50001-UP

2шт.

26

421-93-21170

PLATE, MARK,KOMATSU

SN: 50001-UP

1шт.

27

421-93-21150

PLATE, STRIPE,L.H.

SN: 50001-UP

1шт.

28

421-93-21160

PLATE, STRIPE,R.H.

SN: 50001-UP

1шт.

29

09659-53000

PLATE, SAFETY,ACCUMULATOR

SN: 50001-UP

3шт.

30

09960-01001

PLATE, MARK,HANDLING

SN: 50001-UP

4шт.
