Запчасти Komatsu WA470-3 ДЕРЖАТЕЛЬ ФОРСУНКИ(ВНУТР. ЧАСТИ) [ДВИГАТЕЛЬ]

1*

X16-0350530

INJECTION NOZZLE UNIT

Field_1: 60721-

1шт.

1*

X16-0358220

INJECTION NOZZLE UNIT

Field_1: 67604-

1шт.

1

6152-12-3110

HOLDER ASS'Y

Field_1: 60721-

6шт.

|$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

2

DK150508-3300

PIN

Field_1: 60721-

2шт.

3

DK150550-5900

ROD,PUSH

Field_1: 60721-

1шт.

4

DK150562-6200

SPRING,NOZZLE

Field_1: 60721-

1шт.

5

DK150590-0600

SHIM,0.40MM

Field_1: 60721-

-2шт.

|$8

DK150590-0700

SHIM,0.50MM

Field_1: 60721-

-2шт.

|$9

DK150590-0800

SHIM,0.52MM

Field_1: 60721-

-2шт.

|$10

DK150590-0900

SHIM,0.54MM

Field_1: 60721-

-2шт.

|$11

DK150590-1000

SHIM,0.56MM

Field_1: 60721-

-2шт.

|$12

DK150590-1100

SHIM,0.58MM

Field_1: 60721-

-2шт.

|$13

DK150590-1200

SHIM,0.60MM

Field_1: 60721-

-2шт.

|$14

DK150590-1300

SHIM,0.70MM

Field_1: 60721-

-2шт.

6

DK150524-4300

SPACER

Field_1: 60721-

1шт.

7

DK150650-9400

NUT,RETAINING

Field_1: 60721-

1шт.

8

DK029300-5070

GASKET

Field_1: 60721-

1шт.

9

DK150645-8100

CONNECTOR

Field_1: 60721-

1шт.

10

6127-11-3152

BOLT,JOINT

Field_1: 60721-

1шт.

11

07005-00812

GASKET

Field_1: 60721-

2шт.
