Запчасти Komatsu WA470-3 ТОПЛ. НАСОС(СОЕДИНЕНИЕ)(ВНУТР. ЧАСТИ) [ДВИГАТЕЛЬ]

1*

X16-0354000

INJECTION PUMP UNIT

Field_1: 61589-70945

1шт.

|$1

6152-72-1440

INJECTION PUMP A THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3K5 TO A4010-G3K5.

Field_1: 61589-70945

1шт.

|$2

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW

-1шт.

|$3

DK 105664-0431

COUPLING ASS'Y

Field_1: 61589-70945

1шт.

1

DK 156631-4200

COUPLING

Field_1: 61589-70945

1шт.

2

DK 156633-8600

BOLT

Field_1: 61589-70945

2шт.

3

DK 156605-5920

PLATE

Field_1: 61589-70945

1шт.

4

DK 156617-2400

NUT

Field_1: 61589-70945

2шт.

5

DK 156634-0200

BOLT

Field_1: 61589-70945

2шт.

6

DK 156609-5100

COUPLING,CROSS

Field_1: 61589-70945

1шт.

7

DK 156634-0200

BOLT

Field_1: 61589-70945

2шт.

8

DK 156605-5920

PLATE

Field_1: 61589-70945

1шт.

9

DK 156633-4900

BOLT

Field_1: 61589-70945

2шт.

10

DK 156633-5200

BOLT

Field_1: 61589-70945

1шт.

11

DK 156615-2600

WASHER

Field_1: 61589-70945

1шт.

|$15

DK 156637-2820

COUPLING ASS'YII

Field_1: 61589-70945

1шт.

12

DK 156637-2800

COUPLING

Field_1: 61589-70945

1шт.

13

DK 013121-8020

NUT

Field_1: 61589-70945

1шт.

14

DK 023641-8410

WASHER,SPRING

Field_1: 61589-70945

1шт.
