Запчасти Komatsu WA470-3 БЛОК В СБОРЕ,ОХЛАЖД-Е(/) [РАМА И ЧАСТИ КОРПУСА]

|$0

ND445800-9851

UNIT ASSY, COOLING

Field_1: 25001-

1шт.

1

ND245420-2742

CASE SUB-ASSY, COOLING UNIT

Field_1: 25001-

1шт.

2

ND447600-3911

EVAPORATOR SUB-ASSY

Field_1: 25001-

1шт.

2-1A

ND949142-0020

O-RING

Field_1: 25001-

1шт.

3

ND447500-0180

VALVE,EXPANSION

Field_1: 25001-

1шт.

4

ND145511-0040

HOLDER,REMOTE BULB,PARTS Р®іЦЖч,µЖ

Field_1: 25001-

1шт.

5

ND146639-7250

PACKING

Field_1: 25001-

1шт.

6

ND446170-9111

TUBE&ACCESSORY ASSY, AIRCONDITIONER

Field_1: 25001-

1шт.

6-1

.ND446890-5571

TUBE, LIQUID

Field_1: 25001-

1шт.

6-1A

.ND949142-0010

O-RING

Field_1: 25001-

3шт.

6-2

ND443440-0030

SWITCH, PRESSURE

Field_1: 25001-

1шт.

7

ND077500-2580

THERMISTOR ASSY

Field_1: 25001-

1шт.

8

ND146690-5360

CLAMP

Field_1: 25001-

1шт.

9

ND90930-05208

SCREW, PAN TAPPING

Field_1: 25001-

3шт.

10

ND113622-0200

COVER

Field_1: 25001-

1шт.

11

ND116420-1780

CORE SUB-ASSY, HEATER

Field_1: 25001-

1шт.

12

ND245420-3551

CASE SUB-ASSY,COOLING UNIT

Field_1: 25001-

1шт.

13

ND949001-1730

SCREW,TAPPING

Field_1: 25001-

6шт.

14

ND113650-1211

VALVE&ACCESSORY ASSY, WATER±ёУГ·§ЧЬіЙ,Л®

Field_1: 25001-

1шт.

14-1

ND113600-8512

VALVE ASSY, WATER

Field_1: 25001-

1шт.

14-2

ND017264-9300

HOSE,WATER

Field_1: 25001-

1шт.

14-3

ND949351-0720

CLIP,HOSE

Field_1: 25001-

3шт.

14-3

ND949351-0860

CLIP,HOSE

Field_1: 25001-

3шт.

14-4

ND017441-5450

VALVE,WATER

Field_1: 25001-

1шт.

14-5

ND7052-200450

HOSE,WATER

Field_1: 25001-

1шт.

14-7

ND113621-2951

BRACKET

Field_1: 25001-

1шт.

14-8

ND949001-2500

SCREW,TAPPING

Field_1: 25001-

2шт.

15

ND949351-0860

CLIP,HOSE

Field_1: 25001-

1шт.

16

ND90930-05161

SCREW, PAN TAPPING

Field_1: 25001-

2шт.

17

ND246780-4220

CLAMP,PIPING

Field_1: 25001-

1шт.

18

ND246780-4000

CLAMP,PIPING

Field_1: 25001-

1шт.

19

ND949001-2690

SCREW,TAPPING

Field_1: 25001-

7шт.

20

ND063700-6280

SERVOMOTOR ASSY

Field_1: 25001-

1шт.

21

ND116662-1860

SHAFT

Field_1: 25001-

1шт.

22

ND246680-2810

CLAMP,PIPING

Field_1: 25001-

1шт.

23

ND90940-05121

SCREW,BINDING TAPPING

Field_1: 25001-

1шт.

24

ND145530-0250

HOLDER SUB-ASSY, FILTER

Field_1: 25001-

1шт.

25

ND246622-1690

PACKING

Field_1: 25001-

3шт.
