Запчасти Komatsu WA470-3 ТРАНСМИССИЯ(3 МУФТА ) [ТРАНСМИССИЯ]

|$0

714-07-X0011

TRANSMISSION ASS'Y THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2201 TO 2271

Field_1: 25001-

1шт.

|$1

714-07-13500

CLUTCH ASS'Y,3RD AND 4TH THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2225 TO 2226

Field_1: 25001-

1шт.

1

714-07-12661

PISTON,3RD

Field_1: 25001-

1шт.

2

714-07-12740

RING,SEAL

Field_1: 25001-

1шт.

3

714-07-19320

RING,SEAL

Field_1: 25001-

1шт.

4

714-07-12670

DISC

Field_1: 25001-

6шт.

5

714-07-12680

PLATE,SEPARATE

Field_1: 25001-

7шт.

6

714-07-12781

SPRING,WAVE

Field_1: 25001-

6шт.

7

714-07-12711

PLATE,END

Field_1: 25001-

1шт.

8

714-07-12720

RING,SNAP

Field_1: 25001-

1шт.

9

0

GEAR,43-49 TEETH,3RD

Field_1: 25001-

1шт.

10

56B-15-19410

BEARING,NEEDLE

Field_1: 25001-

2шт.

11

714-07-12210

WASHER,THRUST

Field_1: 25001-

2шт.

12

714-07-12930

WASHER,THRUST

Field_1: 25001-

1шт.

13

714-07-12250

SPACER

Field_1: 25001-

1шт.

14

714-07-19340

BEARING

Field_1: 25001-

1шт.
