Запчасти Komatsu WA450L-3 КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (НИЖНИЙ КЛАПАН) СИЛОВАЯ ПЕРЕДАЧА

|$3

714-07-10001

TRANSMISSION ASS'Y

SN: 53302-UP

1шт.

|$4

714-07-10000

TRANSMISSION ASS'Y

SN: 53001-53301

1шт.

|$5

714-07-10041

TRANSMISSION ASS'Y

SN: 53302-UP

1шт.

|$$4

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.

-1шт.

|$7

714-07-15012

VALVE ASS'Y,TRANSMISSION

SN: 53302-UP

1шт.

|$8

714-07-15011

VALVE ASS'Y,TRANSMISSION

SN: 53001-53301

1шт.

|$$7

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 TO F4350-63A0.

-1шт.

|$10

714-07-16100

VALVE ASS'Y,LOWER

SN: 53001-UP

1шт.

1

714-07-16110

BODY,LOWER VALVE

SN: 53001-UP

1шт.

2

714-07-16250

VALVE,PRIORITY

SN: 53001-UP

1шт.

3

714-07-16510

VALVE,F-R

SN: 53001-UP

1шт.

4

714-07-16520

VALVE,H-L

SN: 53001-UP

1шт.

5

714-07-16331

VALVE,SPEED

SN: 53001-UP

1шт.

6

714-07-16340

VALVE,BRAKE

SN: 53001-UP

1шт.

7

714-07-16620

SLEEVE

SN: 53001-UP

2шт.

8

02720-10104

PLUG

SN: 53001-UP

6шт.

9

714-07-16570

PLUG

SN: 53001-UP

2шт.

10

04260-00635

BALL,CHECK VALVE

SN: 53001-UP

2шт.

11

714-07-16590

SPRING,CHECK VALVE

SN: 53001-UP

2шт.

12

419-15-16631

SPACER

SN: 53001-UP

2шт.

13

714-07-16260

SPRING,PRIORITY VALVE

SN: 53001-UP

1шт.

14

714-07-16370

SPRING,F-R VALVE

SN: 53001-UP

2шт.

15

419-15-16620

SPRING,H-L AND SPEED VALVE

SN: 53001-UP

2шт.

16

714-07-16380

SPRING,BRAKE VALVE

SN: 53001-UP

1шт.

17

714-07-16270

STOPPER

SN: 53001-UP

1шт.

18

419-15-15640

PLUG

SN: 53001-UP

3шт.

19

714-07-16842

COVER,LOWER VALVE, L.H.

SN: 53001-UP

1шт.

20

714-07-16851

COVER,LOWER VALVE, R.H.

SN: 53001-UP

1шт.

21

714-07-16950

GASKET,LOWER VALVE, L.H. (K2)

SN: 53001-UP

1шт.

22

714-07-16960

GASKET,LOWER VALVE, R.H. (K2)

SN: 53001-UP

1шт.

23

17A-15-17271

SOLENOID VALVE

SN: 53001-UP

4шт.

24

714-07-16730

VALVE ASS'Y,SOLENOID

SN: 53001-UP

1шт.

25

421-06-16510

O-RING (K2)

SN: 53001-UP

1шт.

26

421-06-16520

O-RING (K2)

SN: 53001-UP

1шт.

27

01220-40412

SCREW

SN: 53001-UP

16шт.

28

01220-40416

SCREW

SN: 53001-UP

4шт.

29

01220-40406

SCREW

SN: 53001-UP

1шт.

30

01010-80835

BOLT

SN: 53001-UP

7шт.

31

01252-40845

BOLT

SN: 53001-UP

2шт.

32

01252-40835

BOLT

SN: 53001-UP

12шт.

33

01252-40825

BOLT

SN: 53001-UP

2шт.

34

07042-30108

PLUG

SN: 53001-UP

2шт.
