Артикул
Название
Примечание
Количество
|$3
714-07-10001
TRANSMISSION ASS'Y
SN: 53302-UP
1шт.
|$4
714-07-10000
TRANSMISSION ASS'Y
SN: 53001-53301
1шт.
|$5
714-07-10041
TRANSMISSION ASS'Y
SN: 53302-UP
1шт.
|$$4
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.
-1шт.
|$7
714-07-15012
VALVE ASS'Y,TRANSMISSION
SN: 53302-UP
1шт.
|$8
714-07-15011
VALVE ASS'Y,TRANSMISSION
SN: 53001-53301
1шт.
|$$7
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 TO F4350-63A0.
-1шт.
|$11
714-07-15101
VALVE ASS'Y,UPPER
SN: 53001-UP
1шт.
1
714-07-15110
BODY,UPPER VALVE
SN: 53001-UP
1шт.
2
714-07-15220
VALVE,MAIN
SN: 53001-UP
1шт.
3
714-07-15231
VALVE,MODULATION
SN: 53001-UP
1шт.
4
714-07-15240
PISTON,MODULATION
SN: 53001-UP
1шт.
5
714-07-15360
VALVE,PILOT
SN: 53001-UP
1шт.
6
714-07-15550
VALVE,TORQUE CONVERTER OUTLET
SN: 53001-UP
1шт.
8
714-07-15560
VALVE,MANUAL
SN: 53001-UP
1шт.
9
415-15-15470
PLUG
SN: 53001-UP
1шт.
13
714-07-15271
SPRING,MAIN VALVE
SN: 53001-UP
1шт.
14
714-07-15570
SPRING,MODULATION VALVE
SN: 53001-UP
1шт.
15
714-07-15680
SPRING,PILOT VALVE
SN: 53001-UP
1шт.
18
714-07-15810
COVER,UPPER VALVE, L.H.
SN: 53001-UP
1шт.
19
714-07-15820
COVER,UPPER VALVE, R.H.
SN: 53001-UP
1шт.
20
714-07-15930
GASKET,UPPER VALVE, L.H. (K2)
SN: 53001-UP
1шт.
21
714-07-15940
GASKET,UPPER VALVE, R.H. (K2)
SN: 53001-UP
1шт.
25
569-15-45610
SOLENOID VALVE,SOLENOID
SN: 53302-UP
1шт.
25
714-10-15611
VALVE,SOLENOID
SN: 53001-53301
1шт.
26
01252-40622
BOLT
SN: 53001-UP
4шт.
28
07040-11812
PLUG
SN: 53001-UP
1шт.
30
714-07-15450
ORIFICE
SN: 53001-UP
2шт.
35
714-07-15861
BRACKET
SN: 53001-UP
1шт.
Выбрано товаров: 44
