Запчасти Komatsu WA450-5L ТРАНСМИССИЯ (1 И 4 МУФТА) СИЛОВАЯ ПЕРЕДАЧА

|$4

TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)

SN: A36166-UP

-1шт.

|$5

TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)

SN: A36001-A36165

-1шт.

|$6

TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)

SN: A36166-UP

-1шт.

|$7

TORQFLOW ASS'Y,(SEE FIG. F4350-01A0)

SN: A36001-A36165

-1шт.

|$8

714-07-22021

CLUTCH,1ST AND 4TH

SN: A36001-UP

1шт.

1

714-07-22122

SHAFT AND CYLINDER A,1ST AND 4TH

SN: A36001-UP

1шт.

2

714-07-22661

PISTON,RANGE

SN: A36001-UP

2шт.

3

714-12-19711

DISC

SN: A36001-UP

15шт.

4

714-16-19730

PLATE,SEPARATE

SN: A36001-UP

17шт.

5

56D-15-12710

SPRING,WAVE

SN: A36166-UP

15шт.

|$14

0

SPRING,WAVE

SN: A36001-A36165

15шт.

6

714-12-12610

PLATE,END

SN: A36001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: A36001-UP

2шт.

8

714-16-19220

RING,SEAL

SN: A36001-UP

2шт.

9

714-07-19320

RING,SEAL (KIT)

SN: A36001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: A36001-UP

3шт.

11

714-08-19560

WASHER

SN: A36001-UP

1шт.

12

714-23-19410

BEARING,NEEDLE

SN: A36001-UP

2шт.

13

714-23-19430

BEARING,NEEDLE

SN: A36001-UP

1шт.

14

714-11-12720

SPACER

SN: A36001-UP

1шт.

15

714-07-22550

SNAP RING

SN: A36001-UP

1шт.

16

714-07-22442

GEAR, 64 TEETH,4TH

SN: A36001-UP

1шт.

17

714-07-22432

GEAR,1ST

SN: A36001-UP

1шт.

18

714-07-22512

GEAR, 36 TEETH

SN: A36001-UP

1шт.

19

714-07-29320

BEARING

SN: A36001-UP

1шт.

20

714-12-19340

BEARING,ROLLER

SN: A36001-UP

1шт.

21

419-15-12122

RING (KIT)

SN: A36001-UP

3шт.

|$31

714-07-05020

SERVICE KIT,TRANSMISSION

SN: A36001-UP

1шт.

|$32

714-07-05080

SERVICE KIT,TRANSMISSION (WITH LOCK-UP)

SN: A36001-UP

1шт.
