Запчасти Komatsu WA450-5L ОСНОВН. КОНСТРУКЦИЯ (ПЕРЕКЛЮЧАТЕЛЬ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

08086-20000

SWITCH,START

SN: A36001-UP

1шт.

|$1

08086-20100

SWITCH,START (WITH RUBBER CAPPED KEY)

SN: A36001-UP

1шт.

2

421-06-36211

SWITCH,POWER MODE

SN: A36001-UP

1шт.

3

421-06-36231

SWITCH,T/M SHIFT MODE

SN: A36001-UP

1шт.

4

421-06-36241

KNOB

SN: A36001-UP

2шт.

5

421-06-36142

SWITCH,FAN REVERSE

SN: A36001-UP

1шт.

|$$7

USE QUANTITY OF 2 FOR JRB COUPLER, LOCK-UP TORQUE CONVERTER OR JRB COUPLER WITH AUXILIARY STEERING.

-1шт.

|$$8

OTHER WISE USE QUANTITY OF 1.

-1шт.

6

421-06-36152

SWITCH,T/M CUT OFF

SN: A36001-UP

1шт.

|$$10

USE QUANTITY OF 2 FOR LOCK-UP TORQUE CONVERTER, JRB COUPLER WITH AUXILIARY STEERING, JOYSTICK STEERING, OR

-1шт.

|$$11

STANDARD WITH AUXILIARY STEERING AND HEATER. OTHERWISE USE QUANTITY OF 1.

-1шт.

7

421-06-36180

CAP

SN: A36001-UP

9шт.

8

423-06-31182

WIRING HARNESS

SN: A36001-UP

1шт.

9

08038-00518

CAP

SN: A36001-UP

5шт.

10

421-06-32370

BRACKET

SN: A36001-UP

1шт.

11

01010-81016

BOLT

SN: A36001-UP

1шт.

12

COVER,(SEE FIG. K4200-18A0)

SN: A36001-UP

-1шт.

13

BOX,(SEE FIG. K4200-17A0)

SN: A36001-UP

-1шт.

14

935 522 C1

BAND

SN: A36001-UP

5шт.

15

01643-31032

WASHER

SN: A36001-UP

1шт.

16

418-U77-A640

SWITCH,JRB COUPLER

SN: A36001-UP

1шт.

17

423-879-A610

DECAL

SN: A36001-UP

1шт.
