Запчасти Komatsu WA450-5L ЦИЛИНДР РУЛЕВ. УПР-Я (ВНУТР. ЧАСТИ) ГИДРАВЛИКА

|$0

0

CYLINDER ASS'Y,L.H. (FINAL COATING)

SN: A36001-UP

1шт.

|$1

0

CYLINDER ASS'Y,R.H. (FINAL COATING)

SN: A36001-UP

1шт.

|$2

707-00-0A500

CYLINDER ASS'Y,L.H.

SN: A36001-UP

1шт.

|$3

707-00-0A510

CYLINDER ASS'Y,R.H.

SN: A36001-UP

1шт.

1

707-11-10A81

CYLINDER,L.H.

SN: A36001-UP

1шт.

|$5

707-11-10A91

CYLINDER,R.H.

SN: A36001-UP

1шт.

2

07040-11007

PLUG

SN: A36001-UP

1шт.

3

07002-11023

O-RING (KIT)

SN: A36001-UP

1шт.

4

02896-11015

O-RING (KIT)

SN: A36001-UP

2шт.

5

707-76-55520

BUSHING

SN: A36001-UP

1шт.

6

416-09-11130

SEAL,DUST (KIT)

SN: A36001-UP

2шт.

7

707-29-10620

HEAD,CYLINDER

SN: A36001-UP

1шт.

8

707-52-90250

BUSHING

SN: A36001-UP

1шт.

9

707-51-50030

PACKING,ROD (KIT)

SN: A36001-UP

1шт.

10

707-51-50640

RING,BUFFER (KIT)

SN: A36001-UP

1шт.

11

176-63-92240

SEAL,DUST (KIT)

SN: A36001-UP

1шт.

12

07179-12062

RING,SNAP

SN: A36001-UP

1шт.

13

07000-12095

O-RING (KIT)

SN: A36001-UP

1шт.

14

07146-02096

RING,BACK-UP (KIT)

SN: A36001-UP

1шт.

15

07000-12100

O-RING (KIT)

SN: A36001-UP

1шт.

16

721-58-50930

ROD,PISTON

SN: A36001-UP

1шт.

17

707-76-55120

BUSHING

SN: A36001-UP

1шт.

18

07020-00000

FITTING,GREASE

SN: A36001-UP

1шт.

19

416-09-11130

SEAL,DUST (KIT)

SN: A36001-UP

2шт.

20

707-36-10340

PISTON

SN: A36001-UP

1шт.

21

707-44-10180

RING,PISTON (KIT)

SN: A36001-UP

1шт.

22

07156-01012

RING,WEAR (KIT)

SN: A36001-UP

1шт.

23

07165-13638

NUT

SN: A36001-UP

1шт.

|$28

707-99-32250

SERVICE KIT,STEERING CYLINDER

SN: A36001-UP

2шт.
