Запчасти Komatsu WA450-3MC FIG. Y-A TWO-СЕКЦ. УПРАВЛЯЮЩ. КЛАПАН ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

709-12-13101

VALVE ASSEMBLY

SN: A31001-A31195-UP

1шт.

|$1

709-12-00232

BODY SUB-ASSEMBLY

SN: A31001-A31195-UP

1шт.

1

NSS

BODY, VALVE

SN: A31001-A31195-UP

1шт.

2

700-22-11370

PLUG

SN: A31001-A31195-UP

1шт.

3

07002-12434

O-RING

SN: A31001-A31195-UP

1шт.

4

NSS

SPOOL, DUMP

SN: A31001-A31195-UP

1шт.

5

NSS

SPOOL, LIFT

SN: A31001-A31195-UP

1шт.

6

709-12-12241

PLUG

SN: A31001-A31195-UP

4шт.

7

709-12-12340

RETAINER

SN: A31001-A31195-UP

2шт.

8

709-12-13220

RETAINER

SN: A31001-A31195-UP

1шт.

9

709-12-13260

SPRING

SN: A31001-A31195-UP

1шт.

10

709-12-11760

SPRING

SN: A31001-A31195-UP

1шт.

11

709-12-11260

RETAINER

SN: A31001-A31195-UP

1шт.

12

709-12-11310

CASE

SN: A31001-A31195-UP

2шт.

13

709-12-12320

CASE

SN: A31001-A31195-UP

2шт.

14

07000-12065

O-RING

SN: A31001-A31195-UP

8шт.

15

709-12-12230

PISTON

SN: A31001-A31195-UP

2шт.

16

709-12-13240

PISTON

SN: A31001-A31195-UP

2шт.

17

709-12-12290

SLEEVE

SN: A31001-A31195-UP

2шт.

18

01011-81020

BOLT

SN: A31001-A31195-UP

8шт.

19

01602-21030

WASHER, SPRING

SN: A31001-A31195-UP

8шт.

20

709-12-11411

VALVE, CHECK

SN: A31001-A31195-UP

2шт.

21

709-12-11430

SPRING

SN: A31001-A31195-UP

2шт.

22

709-12-11440

PLATE

SN: A31001-A31195-UP

2шт.

23

07000-13048

O-RING

SN: A31001-A31195-UP

2шт.

24

01010-81235

BOLT

SN: A31001-A31195-UP

8шт.

25

709-12-11590

VALVE

SN: A31001-A31195-UP

1шт.

26

709-12-11520

SEAL

SN: A31001-A31195-UP

1шт.

27

709-12-11530

SPRING

SN: A31001-A31195-UP

1шт.

28

709-12-11570

FLANGE

SN: A31001-A31195-UP

1шт.

29

07000-13048

O-RING

SN: A31001-A31195-UP

1шт.

30

01010-61460

BOLT

SN: A31001-A31195-UP

2шт.

31

01643-31445

WASHER

SN: A31001-A31195-UP

2шт.

32

700-94-11260

PLUG

SN: A31001-A31195-UP

1шт.

33

07002-13634

O-RING

SN: A31001-A31195-UP

1шт.

34

07000-12018

O-RING

SN: A31001-A31195-UP

1шт.

35

07001-02018

RING, BACK-UP

SN: A31001-A31195-UP

1шт.

36

709-12-11611

PLATE

SN: A31001-A31195-UP

1шт.

37

07000-12060

O-RING

SN: A31001-A31195-UP

1шт.

38

01010-61425

BOLT

SN: A31001-A31195-UP

2шт.

39

709-12-11711

SPRING

SN: A31001-A31195-UP

1шт.

40

709-12-13270

SPRING

SN: A31001-A31195-UP

1шт.

41

709-12-11721

SPRING

SN: A31001-A31195-UP

1шт.

42

709-12-13280

SPRING

SN: A31001-A31195-UP

1шт.

43

709-12-11730

SPRING

SN: A31001-A31195-UP

2шт.

44

709-12-13250

SPRING

SN: A31001-A31195-UP

2шт.

45

709-12-13230

RETAINER

SN: A31001-A31195-UP

2шт.

46

709-12-11830

SPACER

SN: A31001-A31195-UP

4шт.

47

709-12-13210

SLEEVE

SN: A31001-A31195-UP

2шт.

|$49

-1шт.

|$50

F1 - ORDER VALVE ASSEMBLY 709-12-13102 WHEN REPLACING THIS ITEM.

-1шт.

|$51

-1шт.
