Запчасти Komatsu WA450-3MC FIG. K7-A ОТОПИТЕЛЬ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

425-07-23110

HEATER UNIT

SN: A31001-UP-UP

1шт.

|$1

ND113140-0120

UNIT ASSEMBLY, HEATER

SN: A31001-UP-UP

1шт.

1

ND245420-4200

CASE ASSEMBLY

SN: A31001-UP-UP

1шт.

2

ND116730-0520

DAMPER ASSEMBLY

SN: A31001-UP-UP

1шт.

3

ND116730-0530

DAMPER ASSEMBLY

SN: A31001-UP-UP

1шт.

4

ND245420-0210

CASE ASSEMBLY

SN: A31001-UP-UP

1шт.

5

ND116452-0561

CASE, HEATER

SN: A31001-UP-UP

1шт.

6

ND949001-1730

SCREW, TAPPING

SN: A31001-UP-UP

11шт.

7

ND116410-9680

UNIT ASSEMBLY, RADIATOR

SN: A31001-UP-UP

1шт.

8

ND116427-5540

PIPE

SN: A31001-UP-UP

1шт.

9

ND7052-200600

HOSE, WATER

SN: A31001-UP-UP

3шт.

10

ND949351-0720

CLAMP, HOSE

SN: A31001-UP-UP

6шт.

11

ND113600-9260

VALVE ASSEMBLY, WATER

SN: A31001-UP-UP

1шт.

12

ND116427-2320

PIPE

SN: A31001-UP-UP

1шт.

13

ND017231-1400

CLAMP

SN: A31001-UP-UP

1шт.

14

ND246440-5200

WIRING HARNESS, WIRE

SN: A31001-UP-UP

1шт.

15

ND017732-3050

LEVER, CONTROL

SN: A31001-UP-UP

1шт.

16

ND91370-03081

SCREW WITH WASHER

SN: A31001-UP-UP

3шт.

17

ND017732-3041

LEVER, CONTROL

SN: A31001-UP-UP

1шт.

18

ND017732-3060

LEVER, CONTROL

SN: A31001-UP-UP

1шт.

19

ND146625-5040

BUSHING

SN: A31001-UP-UP

2шт.

20

ND116662-3780

SHAFT

SN: A31001-UP-UP

1шт.

21

ND246690-2930

CLAMP

SN: A31001-UP-UP

1шт.

22

ND116662-0590

SHAFT

SN: A31001-UP-UP

1шт.

23

ND063700-6580

SERVO MOTOR ASSEMBLY

SN: A31001-UP-UP

1шт.

24

ND146625-2630

BUSHING

SN: A31001-UP-UP

1шт.

25

ND909300-6141

SCREW, TAPPING

SN: A31001-UP-UP

9шт.

26

ND146668-6710

PACKING

SN: A31001-UP-UP

1шт.

27

ND246690-6740

CLAMP

SN: A31001-UP-UP

3шт.

28

ND017773-0140

CLIP

SN: A31001-UP-UP

1шт.

29

ND017773-0180

CLIP

SN: A31001-UP-UP

1шт.

30

ND949008-0780

SCREW, TAPPING

SN: A31001-UP-UP

2шт.

31

ND017660-3490

BRACKET

SN: A31001-UP-UP

2шт.

32

ND90930-05121

SCREW, TAPPING

SN: A31001-UP-UP

3шт.

33

ND146984-4080

GROMMET

SN: A31001-UP-UP

1шт.

34

ND145840-1210

GUIDE, AIR

SN: A31001-UP-UP

1шт.

35

ND146625-7620

BUSHING

SN: A31001-UP-UP

1шт.

36

ND116471-7200

BRACKET, CASE

SN: A31001-UP-UP

2шт.

37

ND116471-7210

BRACKET, CASE

SN: A31001-UP-UP

1шт.
