Запчасти Komatsu WA450-3MC FIG. K7-A ОБОГРЕВАТЕЛЬ./КОНДИЦ. ВОЗДУХА - ВОЗДУХОВОД КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

425-07-21152

DUCT ASSEMBLY, AIR

SN: A31001-UP-UP

2шт.

1

ND145820-9610

DUCT, AIR

SN: A31001-UP-UP

1шт.

2

ND145820-8330

DUCT, AIR

SN: A31001-UP-UP

1шт.

3

ND116530-8560

DAMPER ASSEMBLY

SN: A31001-UP-UP

1шт.

4

ND116530-8570

DAMPER ASSEMBLY

SN: A31001-UP-UP

1шт.

5

ND017732-3080

LEVER, CONTROL

SN: A31001-UP-UP

1шт.

6

ND017732-3090

LEVER, CONTROL

SN: A31001-UP-UP

1шт.

7

ND017732-3100

LEVER, CONTROL

SN: A31001-UP-UP

1шт.

8

ND017732-5020

LEVER, CONTROL

SN: A31001-UP-UP

1шт.

9

ND116662-0640

SHAFT

SN: A31001-UP-UP

1шт.

10

ND949008-0420

SCREW, TAPPING

SN: A31001-UP-UP

2шт.

11

ND913100-3081

SCREW WITH WASHER

SN: A31001-UP-UP

2шт.

12

ND116632-0171

SPRING, HOLDING

SN: A31001-UP-UP

8шт.

13

ND063700-7010

SERVO MOTOR ASSEMBLY

SN: A31001-UP-UP

1шт.

14

ND949008-0780

SCREW, TAPPING

SN: A31001-UP-UP

1шт.

15

ND146625-2630

BUSHING

SN: A31001-UP-UP

3шт.

16

ND246690-2930

CLAMP

SN: A31001-UP-UP

1шт.

17

ND017773-0140

CLIP

SN: A31001-UP-UP

1шт.

18

ND146522-6181

BRACKET

SN: A31001-UP-UP

1шт.

19

ND909400-5161

SCREW, TAPPING

SN: A31001-UP-UP

6шт.

|$20

-1шт.

|$21

F1 - (SEE FIG. K0710-09A0) TO ORDER HEATER SUB-KIT, WHICH CONSISTSOF ALL ITEMS IN THIS FIG. AND (FIG. K0710-03A0)

-1шт.

|$22

-1шт.
