Запчасти Komatsu WA450-3MC FIG. K7-A КОНДИЦ. ВОЗДУХА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

425-07-21102

KIT, AIR CONDITIONER

SN: A31001-UP-UP

1шт.

|$1

425-07-21132

AIR CONDITIONER KIT - SUB-ASSEMBLY

SN: A31001-UP-UP

1шт.

1

NSS

DAMPER ASSEMBLY (SEE FIG. K0710-03A0)

SN: A31001-UP-UP

-1шт.

2

NSS

DUCT ASSEMBLY, AIR (SEE FIG. K0710-04A0)

SN: A31001-UP-UP

-1шт.

3

425-07-21160

RELAY

SN: A31001-UP-UP

8шт.

4

421-07-21190

CAP

SN: A31001-UP-UP

2шт.

5

421-07-21280

HOSE, DRAIN

SN: A31001-UP-UP

2шт.

6

20Y-979-3120

RECEIVER TANK

SN: A31001-UP-UP

1шт.

7

01435-00620

BOLT

SN: A31001-UP-UP

2шт.

8

AIR CONDITIONER UNIT (SEE FIG. K0710-06A2)

SN: A31001-UP-UP

-1шт.

9

425-07-21121

CONTROLLER

SN: A31001-UP-UP

1шт.

10

NSS

COMPRESSOR ASSEMBLY, AIR (SEE FIG. K0710-05A0)

SN: A31001-UP-UP

-1шт.

11

CONDENSER ASSEMBLY (SEE FIG. K0710-08A0)

SN: A31001-UP-UP

-1шт.

12

DUCT, R.H. (SEE FIG. K0712-01A0)

SN: A31001-UP-UP

-1шт.

13

BOX ASSEMBLY (SEE FIG. K0710-02A0)

SN: A31001-UP-UP

-1шт.

14

HOSE (SEE FIG. K0713-01A0)

SN: A31001-A31236-UP

-1шт.

|$17

OR

-1шт.

14

HOSE (SEE FIG. K0713-01A0)

SN: A31237-UP-UP

-1шт.

15

HARNESS, WIRING (SEE FIG. K0711-02A0)

SN: A31001-UP-UP

-1шт.

16

BOLT (SEE FIG. K0711-02A0)

SN: A31001-UP-UP

-1шт.
