Запчасти Komatsu WA450-3L FIG. B-A ГЕНЕРАТОР - A КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$0

1286 822 H91

ALTERNATOR ASSEMBLY

SN: A30001-UP-UP

1шт.

1

1317 211 H1

HOUSING, RECTIFIER

SN: A30001-UP-UP

1шт.

2

1268 346 H91

ROTOR ASSEMBLY

SN: A30001-UP-UP

1шт.

3

1268 347 H91

STATOR ASSEMBLY

SN: A30001-UP-UP

1шт.

4

1268 348 H1

FRAME

SN: A30001-UP-UP

1шт.

5

1268 349 H91

RECTIFIER BRIDGE

SN: A30001-UP-UP

1шт.

6

1268 350 H1

DIODE TRIO

SN: A30001-UP-UP

1шт.

7

1317 212 H1

FIELD COIL AND SUPPORT ASSEMBLY

SN: A30001-UP-UP

1шт.

8

1268 352 H1

COVER, END

SN: A30001-UP-UP

1шт.

9

1299 220 H1

REGULATOR AND RESISTOR ASSEMBLY

SN: A30001-UP-UP

1шт.

10

1268 354 H1

CONNECTOR, OUTPUT TERMINAL

SN: A30001-UP-UP

1шт.

11

1268 355 H1

CONNECTOR, RELAY TERMINAL

SN: A30001-UP-UP

1шт.

12

1268 356 H1

CONNECTOR, REGULATOR

SN: A30001-UP-UP

1шт.

13

1268 357 H91

PACKAGE, OUTPUT TERMINAL

SN: A30001-UP-UP

1шт.

14

1268 358 H91

PACKAGE, RELAY TERMINAL

SN: A30001-UP-UP

1шт.

15

1268 359 H1

CAPACITOR

SN: A30001-UP-UP

1шт.

16

1218 121 H1

PLATE, RETAINER - INSIDE

SN: A30001-UP-UP

1шт.

17

1268 360 H1

PLATE, RETAINER - OUTSIDE

SN: A30001-UP-UP

1шт.

18

1213 268 H1

BEARING, BALL

SN: A30001-UP-UP

1шт.

19

1268 361 H1

COLLAR - INSIDE

SN: A30001-UP-UP

1шт.

20

1307 338 H1

FAN AND BAFFLE ASSEMBLY

SN: A30001-UP-UP

1шт.

21

1317 214 H1

NUT, LOCK

SN: A30001-UP-UP

1шт.

22

1317 214 H1

NUT, LOCK

SN: A30001-UP-UP

3шт.

23

VE8211

NUT, FLANGE

SN: A30001-UP-UP

1шт.

24

BFO266

SCREW, MOUNTING

SN: A30001-UP-UP

3шт.

25

1268 364 H1

SCREW ASSEMBLY, MOUNTING

SN: A30001-UP-UP

2шт.

26

1268 364 H1

SCREW, ASSEMBLY

SN: A30001-UP-UP

1шт.

27

1268 363 H1

SCREW, ATTACHING

SN: A30001-UP-UP

5шт.

28

1213 252 H1

SCREW, ATTACHING

SN: A30001-UP-UP

4шт.

29

1268 365 H1

SCREW AND WASHER ASSEMBLY, MOUNTING

SN: A30001-UP-UP

1шт.

30

1268 366 H1

SCREW ASSEMBLY, MOUNTING

SN: A30001-UP-UP

1шт.

31

1268 367 H1

SCREW ASSEMBLY, ATTACHING

SN: A30001-UP-UP

2шт.

32

1268 365 H1

SCREW AND WASHER ASSEMBLY, MOUNTING

SN: A30001-UP-UP

1шт.

33

1268 369 H1

WASHER

SN: A30001-UP-UP

2шт.

34

389 603 C91

BEARING, RECTIFIER HOUSING

SN: A30001-UP-UP

1шт.

35

1268 371 H1

BOLT, THRU

SN: A30001-UP-UP

4шт.

36

1213 242 H1

BUSHING, PIVOT

SN: A30001-UP-UP

1шт.

37

1268 372 H1

BUSHING, MOUNTING SCREW

SN: A30001-UP-UP

1шт.

38

1213 274 H1

CAP, RELAY TERMINAL

SN: A30001-UP-UP

1шт.

39

1268 374 H1

GROMMET

SN: A30001-UP-UP

1шт.
