Запчасти Komatsu WA450-3L FIG. B-A СТАРТЕР КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$0

1251 635 H92

MOTOR ASSEMBLY, STARTING

SN: A30001-UP-UP

1шт.

1

NSS

BUSHING, DRIVE END

SN: A30001-UP-UP

1шт.

2

NSS

O-RING - BETWEEN HOUSINGS

SN: A30001-UP-UP

1шт.

3

NSS

PLUG, WICK

SN: A30001-UP-UP

1шт.

4

NSS

WICK, OIL RESERVOIR

SN: A30001-UP-UP

1шт.

5

NSS

HOUSING, DRIVE END

SN: A30001-UP-UP

1шт.

|$6

NSS

BOLT, MOUNTING

SN: A30001-UP-UP

6шт.

6

1223 260 H91

HOUSING, DRIVE

SN: A30001-UP-UP

1шт.

7

1223 259 H1

DRIVE, MOTOR

SN: A30001-UP-UP

1шт.

8

NSS

HOUSING ASSEMBLY, LEVER

SN: A30001-UP-UP

1шт.

9

NSS

RING, RETAINING - SHIFT LEVER SHAFT

SN: A30001-UP-UP

1шт.

10

1223 258 H91

HOUSING, LEVER

SN: A30001-UP-UP

1шт.

11

NSS

SEAL, OIL - LEVER HOUSING

SN: A30001-UP-UP

1шт.

12

NSS

WASHER, BRAKE

SN: A30001-UP-UP

1шт.

13

NSS

O-RING, LEVER SHAFT - 1/2 IN.

SN: A30001-UP-UP

1шт.

14

NSS

O-RING, LEVER SHAFT - 3/8 IN.

SN: A30001-UP-UP

1шт.

15

NSS

SHAFT, SHIFT LEVER

SN: A30001-UP-UP

1шт.

16

NSS

LEVER, SHIFT

SN: A30001-UP-UP

1шт.

17

NSS

WICK, LEVER HOUSING

SN: A30001-UP-UP

1шт.

18

NSS

PLUG, WICK

SN: A30001-UP-UP

1шт.

19

NSS

BUSHING, LEVER HOUSING

SN: A30001-UP-UP

1шт.

20

NSS

O-RING - BETWEEN HOUSINGS

SN: A30001-UP-UP

1шт.

21

NSS

O-RING - BETWEEN SWITCH AND LEVER HOUSING

SN: A30001-UP-UP

1шт.

|$23

1245 107 H1

SCREW, LEVER HOUSING

SN: A30001-UP-UP

1шт.

22

NSS

SPACER, DRIVE END

SN: A30001-UP-UP

1шт.

23

1277 066 H1

CABLE - SOLENOID SWITCH TO C.E. TERMINAL

SN: A30001-UP-UP

1шт.

|$26

120 239

WASHER, LOCK - AT SOLENOID SWITCH

SN: A30001-UP-UP

1шт.

|$27

NSS

WASHER, FLAT - AT FRAME END

SN: A30001-UP-UP

1шт.

|$28

NSS

WASHER, LOCK - AT FRAME END

SN: A30001-UP-UP

1шт.

|$29

NSS

NUT, AT END FRAME

SN: A30001-UP-UP

1шт.

|$30

NSS

NUT AND WASHER - AT END FRAME

SN: A30001-UP-UP

1шт.

24

NSS

NUT, LOCK - PLUNGER ROD GUIDE ADJUST

SN: A30001-UP-UP

1шт.

25

1284 359 H1

SWITCH, SOLENOID

SN: A30001-UP-UP

1шт.

|$33

NSS

SCREW AND WASHER, SWITCH MOUNTING

SN: A30001-UP-UP

3шт.

26

1211 271 H1

INSULATOR, FIELD COIL - DRIVE END

SN: A30001-UP-UP

1шт.

27

1211 263 H1

SHOE, POLE

SN: A30001-UP-UP

4шт.

28

1245 108 H1

SCREW, POLE SHOE

SN: A30001-UP-UP

8шт.

29

1228 453 H1

INSULATOR, FIELD COIL

SN: A30001-UP-UP

1шт.

30

1210 061 H1

INSULATOR, INSIDE FRAME

SN: A30001-UP-UP

1шт.

31

1317 255 H1

INSULATOR, OUTSIDE FRAME

SN: A30001-UP-UP

1шт.

32

1228 452 H1

CONNECTOR - FIELD COIL TO SOLENOID

SN: A30001-UP-UP

1шт.

33

1228 454 H1

PIN, SPRING

SN: A30001-UP-UP

2шт.

34

1223 256 H1

ARMATURE

SN: A30001-UP-UP

1шт.

35

NSS

WASHER, THRUST

SN: A30001-UP-UP

1шт.

36

1228 605 H1

COIL ASSEMBLY, FIELD

SN: A30001-UP-UP

1шт.

37

1284 360 H91

PLATE, BRUSH

SN: A30001-UP-UP

1шт.

|$46

NSS

SCREW - FIELD COIL TO PLATE

SN: A30001-UP-UP

4шт.

38

NSS

BRUSH

SN: A30001-UP-UP

4шт.

39

NSS

SPRING, BRUSH

SN: A30001-UP-UP

4шт.

40

1223 265 H1

LEAD, TERMINAL

SN: A30001-UP-UP

1шт.

41

NSS

O-RING - BETWEEN HOUSINGS

SN: A30001-UP-UP

1шт.

42

1223 269 H91

KIT, TERMINAL INSULATOR

SN: A30001-UP-UP

1шт.

43

1223 255 H1

HOUSING ASSEMBLY, COMMUTATOR END

SN: A30001-UP-UP

1шт.

44

NSS

HOUSING, END FRAME

SN: A30001-UP-UP

1шт.

45

NSS

WICK, OIL RESERVOIR

SN: A30001-UP-UP

1шт.

46

NSS

PLUG, WICK

SN: A30001-UP-UP

1шт.

47

NSS

BUSHING, END FRAME

SN: A30001-UP-UP

1шт.

48

1210 066 H1

PLUG, INSPECTION - LEVER HOUSING

SN: A30001-UP-UP

1шт.

49

NSS

GASKET, INSPECTION PLUG

SN: A30001-UP-UP

1шт.

50

1305 531 H1

NUT

SN: A30001-UP-UP

1шт.

51

1211 267 H1

NUT

SN: A30001-UP-UP

2шт.

52

1283 448 H1

SCREW

SN: A30001-UP-UP

3шт.

53

1251 333 H1

SCREW

SN: A30001-UP-UP

1шт.

54

1317 25 H1

BOLT

SN: A30001-UP-UP

1шт.

55

120 385

WASHER

SN: A30001-UP-UP

1шт.

56

120 396

WASHER

SN: A30001-UP-UP

1шт.

57

NSS

SCREW AND WASHER ASSEMBLY, END FRAME

SN: A30001-UP-UP

6шт.

|$85

-1шт.

|$67

1223 266 H91

KIT, BUSHING REPAIR

SN: A30001-UP-UP

1шт.

|$68

1223 267 H91

KIT, SHIFT LEVER REPAIR

SN: A30001-UP-UP

1шт.

|$69

1223 268 H91

KIT, BRUSH REPAIR

SN: A30001-UP-UP

1шт.

|$70

-1шт.

|$71

F1 - INCLUDED IN BUSHING REPAIR KIT.

-1шт.

|$73

-1шт.

|$74

F2 - INCLUDED IN SHIFT LEVER REPAIR KIT.

-1шт.

|$76

-1шт.

|$77

F3 - INCLUDED IN BRUSH REPAIR KIT.

-1шт.

|$78

-1шт.

|$80

F4 - KIT CONSISTS OF NON-SERVICE PARTS: 1 BUSHING, 3 INSULATORSAND AN INSTRUCTION SHEET.

-1шт.

|$82

-1шт.

|$84

-1шт.
