Запчасти Komatsu WA450-3L FIG. A-AA ВОДЯНАЯ ПОМПА ДВИГАТЕЛЬ

|$0

1295 271 H92

PUMP, WATER

1шт.

1

1240 443 H2

SEAL, O-RING

1шт.

2

1246 568 H1

GASKET, CONNECTION

1шт.

3

1238 047 H1

BEARING, BALL

1шт.

4

1294 219 H1

SEAL, O-RING

1шт.

5

1246 575 H1

RING, RETAINING

1шт.

6

1315 131 H1

SEAL, WATER PUMP

1шт.

7

1268 144 H1

RING, RETAINING

1шт.

8

1246 576 H1

SEAL, OIL

1шт.

9

1246 579 H1

IMPELLER, WATER PUMP

1шт.

10

1294 220 H1

SHAFT, WATER PUMP

1шт.

11

1246 580 H1

GEAR, WATER PUMP

1шт.

12

1294 221 H1

BODY, WATER PUMP

1шт.

13

1294 222 H1

SEAL, O-RING

1шт.

14

1294 005 H1

BOLT - M10-1.50 X 25

3шт.

15

6732-11-1910

PLUG, PIPE - 1/2 NPT

1шт.

16

6742-01-1460

PLUG, PIPE - 1 NPT

1шт.

17

1246 536 H1

WASHER, PLAIN - M8

2шт.

18

1246 584 H1

CONNECTION, WATER TRANSFER

1шт.

19

6731-11-9150

BOLT - M10-1.50 X 30

3шт.

20

6732-21-5160

BOLT - M8-1.25 X 25

2шт.

21

1307 125 H1

COVER, WATER PUMP

1шт.

22

1267 723 H91

NIPPLE, COUPLING

1шт.

23

6560-51-7710

SEAL, O-RING

1шт.

|$24

6560-41-4100

PLUG, THREADED - 9/16-18 UNF

1шт.

24

NSS

PLUG, THREADED

1шт.

25

6560-51-7710

SEAL, O-RING

1шт.

26

6732-11-1920

PLUG, PIPE - 3/4 NPT

1шт.

|$28

1294 224 H91

REPAIR KIT, WATER PUMP - MINOR

1шт.

|$29

-1шт.

|$30

F1 - INCLUDED IN WATER PUMP REPAIR KIT.

-1шт.

|$31

-1шт.
