Запчасти Komatsu WA450-3L FIG. A-AB РЕГУЛЯТОР SPRING PACK - VS SPRING PACK ДВИГАТЕЛЬ

|$0

1239 452 H91

COVER VS SPRING PACK

SN: A30001-UP-UP

1шт.

1

1239 341 H91

COVER SPRING PACK

SN: A30001-UP-UP

1шт.

2

1239 230 H1

BUSHING

SN: A30001-UP-UP

2шт.

3

6216-64-8240

SEAL, O-RING

SN: A30001-UP-UP

2шт.

4

1238 182 H1

SCREW, SOCKET SET

SN: A30001-UP-UP

2шт.

5

1240 080 H1

SCREW, SET

SN: A30001-UP-UP

1шт.

6

1239 231 H1

SHAFT, THROTTLE

SN: A30001-UP-UP

1шт.

7

1240 084 H1

STOP, THROTTLE SHAFT

SN: A30001-UP-UP

1шт.

8

1239 233 H1

SEAL, DUST

SN: A30001-UP-UP

2шт.

9

1238 184 H1

NUT, FUEL PUMP ADJUSTING

SN: A30001-UP-UP

2шт.

10

1250 026 H1

NUT - 1/4-28 UNF

SN: A30001-UP-UP

2шт.

11

1238 192 H1

WASHER, PLAIN - 1/4 IN.

SN: A30001-UP-UP

4шт.

|$12

1237 957 H91

PACK, IDLING SPRING

SN: A30001-UP-UP

1шт.

12

1240 082 H1

PLUNGER, GOVERNOR

SN: A30001-UP-UP

1шт.

13

1240 083 H1

RING, RETAINING

SN: A30001-UP-UP

1шт.

14

1240 075 H1

GUIDE, SPRING

SN: A30001-UP-UP

1шт.

15

1240 071 H1

SPRING, IDLING

SN: A30001-UP-UP

1шт.

16

1240 077 H1

SHIM - 0.020 IN.

SN: A30001-UP-UP

-2шт.

|$18

1240 078 H1

SHIM - 0.010 IN.

SN: A30001-UP-UP

-2шт.

|$19

1240 079 H1

SHIM - 0.005 IN.

SN: A30001-UP-UP

-2шт.

17

1241 572 H1

SPRING, GOVERNOR

SN: A30001-UP-UP

1шт.

18

1240 085 H1

PLUNGER, THROTTLE LEVER

SN: A30001-UP-UP

1шт.

19

1240 060 H1

GASKET, SPRING PACK

SN: A30001-UP-UP

2шт.

20

1239 369 H1

BOLT

SN: A30001-UP-UP

6шт.

21

1240 059 H1

WASHER, PLAIN

SN: A30001-UP-UP

1шт.
