Запчасти Komatsu WA450-3L FIG. A-AA ТОПЛИВН. НАСОС ПЕРЕДН. COVER ДВИГАТЕЛЬ

|$0

1239 601 H91

FRONT COVER VS, FUEL PUMP

1шт.

|$1

1239 574 H92

COVER AND BUSHING

1шт.

1

1239 494 H3

COVER, FUEL PUMP

1шт.

2

1238 391 H1

BUSHING

2шт.

3

1238 859 H1

SEAL, OIL

1шт.

4

1238 865 H1

HUB, JAW COUPLING

1шт.

5

1238 867 H1

KEY, DRIVE GEAR

1шт.

6

1238 858 H1

GEAR, TACHOMETER DRIVE

1шт.

|$8

1239 339 H91

SHAFT, TACHOMETER DRIVE

1шт.

7

1238 862 H1

SHAFT, TACHOMETER DRIVE

1шт.

8

1238 863 H1

BUSHING, TACHOMETER DRIVE

1шт.

9

1238 864 H1

GEAR, TACHOMETER DRIVE

1шт.

10

1239 025 H1

CONNECTOR, MALE

1шт.

11

1239 092 H1

SPACER, SEAL

1шт.

|$14

1239 575 H91

MAIN DRIVE ASSEMBLY

1шт.

12

1238 050 H1

BEARING, BALL

1шт.

13

1238 857 H1

SHAFT, FUEL PUMP DRIVE

1шт.

14

1238 860 H1

RING, RETAINING

1шт.

15

1313 050 H1

GEAR, FUEL PUMP

1шт.

16

1238 866 H1

ADAPTER, SPLINE

1шт.

17

1241 525 H1

SEAL, OIL

2шт.

|$21

1237 931 H91

SHAFT, IDLER GEAR

1шт.

18

1238 266 H1

RING, RETAINING

1шт.

19

1238 593 H1

BUSHING

1шт.

20

1238 602 H1

RING, THRUST

1шт.

|$25

1237 940 H91

SHAFT, GEAR

1шт.

21

6731-31-6210

GEAR, IDLER

1шт.

22

NSS

SHAFT, IDLER

1шт.

23

1238 005 H1

BOLT

1шт.

24

1238 334 H1

WASHER, PLAIN - 5/16 IN.

1шт.

25

1238 068 H1

BOLT

1шт.

26

1240 081 H1

WASHER, SEALING

1шт.

|$32

1239 508 H91

WEIGHT ASSEMBLY, UPPER

1шт.

27

1238 388 H1

WEIGHT, GOVERNOR

2шт.

28

1238 843 H1

SHAFT, GOVERNOR

1шт.

29

1238 844 H1

PIN, GOVERNOR

2шт.

30

1238 845 H1

GEAR, GOVERNOR

1шт.

31

1239 125 H1

CARRIER, GOVERNOR

1шт.

|$38

1239 509 H91

WEIGHT ASSEMBLY, LOWER

1шт.

32

1238 843 H1

SHAFT, GOVERNOR

1шт.

33

1238 844 H1

PIN, GOVERNOR

2шт.

34

1238 845 H1

GEAR, GOVERNOR

1шт.

35

1239 125 H1

CARRIER, GOVERNOR

1шт.

36

1238 337 H1

WEIGHT, GOVERNOR

2шт.

37

1238 313 H1

SHIM

7шт.

38

1238 309 H1

SPRING, COMPRESSION

1шт.

39

1238 312 H1

PLUNGER, GOVERNOR WEIGHT ASSIST

1шт.

40

1239 369 H1

BOLT - 1/4-20 X 1 1/8 IN.

8шт.

41

6560-51-3910

BOLT, SOCKET HEAD -3/16-24 X 1 1/4 IN.

1шт.

42

1296 763 H1

GASKET, FUEL PUMP

1шт.

43

6560-51-3950

WASHER, LOCK - 5/16 IN.

1шт.

44

1238 155 H1

WASHER, PLAIN - 1/8 IN.

1шт.

45

1239 580 H1

BOLT

1шт.

46

1315 182 H1

GASKET, FUEL PUMP

1шт.

47

1294 740 H1

BOLT, TWELVE POINT CAP

1шт.
