Запчасти Komatsu WA450-3L FIG. A-AA СИСТЕМА СМАЗКИ МАСЛООХЛАДИТЕЛЬ ДВИГАТЕЛЬ

|$0

1296 279 H92

ASSEMBLY, LUBRICATING OIL FILTER

1шт.

1

6731-51-5180

HEAD, LUBRICATING OIL FILTER

1шт.

2

1294 146 H1

PLUNGER, BY-PASS VALVE

1шт.

3

1294 151 H1

SPRING, COMPRESSION

1шт.

4

1294 148 H1

RING, RETAINING

1шт.

5

1294 149 H1

RING, RETAINING

1шт.

6

1294 145 H1

THERMOSTAT

1шт.

7

6560-41-4100

PLUG, THREADED - 9/16-18 UNF

2шт.

8

6560-51-7710

SEAL, O-RING

1шт.

9

1246 131 H91

PLUG, THREADED - 3/4-16 UNF

1шт.

10

6735-21-4160

SEAL, O-RING

1шт.

|$11

1294 144 H91

PLUG, THREADED - 1 3/16-12 UN

1шт.

11

NSS

PLUG, THREADED

1шт.

12

6216-74-6220

SEAL, O-RING

1шт.

13

6732-61-2240

PLUG, PIPE - 1/4 NPT

1шт.

14

1294 150 H1

PLUG, EXPANSION - 7/8 IN.

1шт.

15

1239 934 H91

PLUG, THREADED - 1 1/16-12 UNF

1шт.

16

6560-41-8140

SEAL, O-RING

1шт.

17

6741-61-2120

SEAL, O-RING

1шт.

18

1294 485 H1

BOLT

2шт.

19

1294 140 H1

GASKET, FILTER HEAD

1шт.

20

1240 555 H2

GASKET, OIL COOLER SUPPORT

2шт.

21

1310 933 H1

BOLT - M10-1.50 X 30

3шт.

22

1304 981 H2

COOLER, LUBRICATING OIL

1шт.

23

6731-11-9150

BOLT - M10-1.50 X 30

4шт.

24

1313 068 H1

BOLT - M10-1.50 X 170

6шт.

25

1296 840 H1

SEAL, RECTANGULAR RING

2шт.

26

1304 982 H1

SEAL, O-RING

2шт.

27

1317 022 H1

RETAINER, CONNECTION

1шт.

28

1304 984 H1

ADAPTER, O-RING

2шт.

29

6216-64-4230

PIN, ROLL

1шт.

30

6741-51-5230

ELBOW, MALE UNION

2шт.

31

6731-51-6290

ADAPTER, FILTER HEAD

1шт.

32

6731-51-6280

COVER, FILTER HEAD

1шт.

33

1296 862 H1

SEAL, RECTANGULAR RING

1шт.

34

6731-11-8290

SEAL, RECTANGULAR RING

1шт.

35

1246 346 H1

UNION, MALE

1шт.

|$37

NSS

UNION, MALE

1шт.

|$38

1241 538 H1

SEAL, O-RING

1шт.
